Multiprocessor system on a chip
An SoC integrating multiple processor cores for parallel computing.
A multiprocessor system on a chip (MPSoC) is a system on a chip (SoC) that integrates more than one processor core on a single microchip. By definition, an MPSoC has multiple processor cores, which may be microcontrollers, microprocessors, digital signal processors (DSPs), or application-specific instruction set processors (ASIPs). This design allows parallel processing and is notable for enabling higher performance within the compact, energy-efficient footprint characteristic of SoCs.
- Definition
- An SoC with more than one processor core
- Common processor types
- microcontroller, microprocessor, DSP, ASIP
- Typical memory technologies
- ROM, RAM, EEPROM, flash memory, SRAM, DRAM
- Common interfaces
- USB, Ethernet, USART, SPI, HDMI, I²C, CSI, Wi-Fi, Bluetooth, 6LoWPAN, NFC
- Typical applications
- mobile computing, embedded systems, edge computing, AI acceleration, machine vision, data collection, telemetry, vector processing, ambient intelligence
Lore & Background
Multiprocessor SoCs are a type of SoC that, by definition, contain more than one processor core. These cores can be heterogeneous, combining different types such as a general-purpose microprocessor with a digital signal processor (DSP) or an application-specific instruction set processor (ASIP). ASIPs have instruction sets customized for a specific application domain, designed to be more efficient than general-purpose instructions for particular workloads. DSP cores, often included in MPSoCs, typically feature very long instruction word (VLIW) and single instruction, multiple data (SIMD) architectures, making them highly amenable to exploiting instruction-level parallelism through parallel processing and superscalar execution. They often include application-specific instructions such as multiply-accumulate, Fast Fourier transform, fused multiply-add, and convolutions.
Reader's Guide
Multiprocessor SoCs represent a significant evolution in integrated circuit design, enabling higher computational performance within the power and space constraints of mobile and embedded devices. By placing multiple cores on a single die, they allow parallel execution of tasks, which is critical for applications like AI acceleration, embedded machine vision, and real-time data processing at the edge. The use of heterogeneous cores—such as combining a general-purpose CPU with a DSP or ASIP—allows the system to efficiently handle diverse workloads, from general computing to specialized signal processing. This architecture is foundational to modern mobile computing SoCs, which bundle processors, on-chip caches, wireless networking, and often camera hardware. The trade-off for this integration is reduced modularity and component replaceability compared to multi-chip designs, but the gains in power efficiency, reliability, and performance have made MPSoCs ubiquitous in smartphones, tablets, smartwatches, and increasingly in laptops and embedded systems where previously only microcontrollers were used.
Did You Know?
- An MPSoC must have more than one processor core by definition.
- Processor cores in an MPSoC can be microcontrollers, microprocessors, DSPs, or ASIPs.
- DSP cores in MPSoCs often use VLIW and SIMD instruction set architectures.
- MPSoCs are common in mobile computing devices such as smartphones and tablets.
Frequently Asked Questions
What is a Multiprocessor system on a chip (MPSoC)?
An MPSoC is a system-on-chip design that packs more than one processor core onto a single microchip. This multi-core arrangement enables parallel processing while keeping the compact, power-efficient form factor that defines SoCs in general.
What kinds of processor cores can an MPSoC integrate?
The cores in an MPSoC can be microcontrollers, general-purpose microprocessors, digital signal processors, or application-specific instruction set processors. The particular mix is chosen to match the workload the chip needs to handle.
How does an MPSoC differ from a standard single-core SoC?
The defining distinction is that an MPSoC contains multiple processor cores working in parallel, whereas a basic SoC typically has just one. This parallelism lets the chip deliver higher throughput within the same small, energy-efficient footprint.
Where do you typically see MPSoCs used?
They show up in mobile computing, embedded systems, edge computing, AI acceleration, machine vision, telemetry, and ambient-intelligence applications. Any scenario that demands parallel computation in a tight power and space budget is a natural fit.
What memory and interface technologies are common in MPSoC designs?
Memory options range from ROM, RAM, EEPROM, and flash to SRAM and DRAM, while connectivity spans USB, Ethernet, SPI, I²C, HDMI, Wi-Fi, Bluetooth, NFC, and others. These choices let a single chip handle everything from data storage to wireless communication.
