Lunar penetrometer
Unused NASA device to measure lunar surface hardness.
The lunar penetrometer was a cylindrical, battery-powered instrument built to test how well the Moon’s surface could support a landing spacecraft. NASA designed it to be released from an orbiter, fall to the ground, and radio back data on the impact. Although engineers proposed using similar devices on several Moon and planetary missions, the agency never actually deployed the specific spherical omnidirectional version described here.
Development began in the early 1960s under NASA Langley Research Center’s Lunar Penetrometer Program. At that time, the Space Race pushed NASA to prioritize landing astronauts on the Moon over purely scientific exploration. Projects like Ranger and Surveyor were redirected to support Apollo. A key challenge was that Earth-based telescopes and radar could map large features like mountains and craters but could not resolve small-scale surface texture or hardness. In 1961, NASA chief engineer Abe Silverstein told Congress that Ranger could gather needed data on lunar topography. After funding was approved, he directed NASA labs to design instruments that could measure surface firmness.
The penetrometer program produced an impact-sensing projectile. Inside was an accelerometer that recorded the deceleration pattern as it struck the ground, revealing hardness, bearing strength, and how easily the surface could be penetrated. A radio transmitter sent that data to a receiver. The full acceleration history would also have let researchers determine whether the soil was granular, powdery, or brittle. NASA planned to use the device on uncrewed Ranger and Surveyor missions and later on Apollo. However, in August 1963, Jet Propulsion Laboratory manager Robert Meghreblian decided the approach was too risky. Instead, the agency chose gamma-ray spectrometry for composition, and television and radar for topography. In 1966, the penetrometer was again considered as a sounding device for Apollo, but there is no record it was ever used.
The penetrometer was designed to work regardless of its orientation at impact, which mattered on the nearly airless Moon. Its spherical shell housed an omnidirectional acceleration sensor at the center, surrounded by concentric rings of batteries and electronics. An electromagnetic shield enclosed these components, and a ring antenna circled the outside.
- Field
- Lunar exploration instrumentation
- Developed by
- NASA Langley Research Center
- Program
- Lunar Penetrometer Program
- Design type
- Cylindrical or dart-like penetrometer
- Key components
- Omnidirectional accelerometer, telemetry system, balsa wood impact limiter
- Status
- Never fielded
Lore & Background
The lunar penetrometer was first developed in the early 1960s as part of NASA Langley Research Center's Lunar Penetrometer Program. It was created in response to a directive from NASA's chief engineer Abe Silverstein, who sought instruments to return information on the hardness of the lunar surface to support the Apollo program. The device housed an impact accelerometer to measure deceleration time history and a radio telemeter to transmit data to a remote receiver, allowing researchers to ascertain soil composition. The specific spherical omnidirectional penetrometer described here was not flown on the Ranger, Surveyor, or Apollo missions.
Reader's Guide
The lunar penetrometer represents a technological path not taken in the race to land on the Moon. Although it was designed to solve a critical problem—determining the surface characteristics of the Moon for safe landings and locomotion—it was deemed too risky by Jet Propulsion Laboratory manager Robert Meghreblian in August 1963. Instead, NASA relied on gamma-ray spectrometry, television photography, and radar probing. The device was later investigated as a potential sounding device for Apollo in 1966, but no information exists on its use. Its legacy lies in its innovative omnidirectional design, which allowed it to function regardless of orientation, and in the technical challenges it addressed, such as impact sensing and telemetry relay. The lunar penetrometer remains a footnote in lunar exploration history, illustrating the difficult trade-offs between risk and data acquisition during the Space Race.
