Haswell (microarchitecture)
Intel's 2013 microarchitecture with improved power and performance.
Haswell is a CPU microarchitecture developed by Intel, introduced in 2013 as the 'tock' in the company's Tick–tock production model. It uses the same 22 nm FinFET manufacturing process as its predecessor, Ivy Bridge, and focuses on architectural improvements. Haswell supports the x86 instruction set and its 64-bit variant, x86-64, and was marketed as the 4th generation Core, v3-suffixed Xeon processors, and various Pentium and Celeron models.
Quick Facts
- Produced-Start
- June 4, 2013
- Numcores
- 2–4 (mainstream) · 6–8 (enthusiast) · 2–18 (Xeon)
- Cpuid
- 0306C3h
- Code
- 80646 (desktop LGA 1150) · 80647 (mobile Socket G3) · 80648 (desktop LGA 2011-3) · 80644 (server LGA 2011-3)
- Gpu
- HD Graphics 4200 · HD Graphics 4400 · HD Graphics 4600 · HD Graphics 5000 · Iris 5100 · Iris Pro 5200
- Arch
- x86-16, IA-32, x86-64
- Microarch
- Haswell
- Extensions
- AES-NI, CLMUL, RDRAND, TXT
Facts from the source article.
Lore & Background
Haswell was first demonstrated at the 2011 Intel Developer Forum, with official announcement on June 4, 2013 at Computex Taipei. Commercial sales began for manufacturers and OEMs in mid-2013, with standalone desktop chips in September 2013. The architecture was designed to optimize power savings and performance benefits from FinFET transistors on the improved 22 nm process node. Haswell launched in three major forms: desktop (LGA 1150 and LGA 2011-v3 sockets), mobile/laptop (PGA socket), and BGA versions including Haswell-H (47 W and 57 W TDP), Haswell-ULT (13.5 W and 15 W TDP for Ultrabooks), and Haswell-ULX (10 W TDP for tablets). Only certain quad-core variants and BGA R-series SKUs received GT3e integrated graphics with Intel Iris Pro 5200; other models had GT3, GT2, or GT1 graphics. Due to low power requirements, Haswell-ULT and Haswell-ULX were only available in dual-core configurations. A refresh called Haswell Refresh was released around mid-2014, offering modest clock frequency increases, supported by Intel's 9 Series chipsets. The Devil's Canyon CPUs (i5 and i7 K-series) used an improved thermal interface material called NGPTIM, reducing operating temperatures and improving overclocking potential.
Reader's Guide
Haswell's significance lies in its architectural refinements over Ivy Bridge, including a wider core with a fourth ALU, third AGU, and second BEU, deeper buffers, and higher cache bandwidth. It introduced full 256-bit AVX execution units, new instructions (AVX2, BMI1, BMI2, ABM, FMA3), and Intel Transactional Synchronization Extensions (TSX) on the Haswell-EX variant, though a bug in TSX led to its disabling via microcode update in August 2014. The fully integrated voltage regulator (FIVR) moved voltage regulation components from the motherboard onto the CPU. Performance improvements included approximately 8% faster vector processing, up to 5% higher single-threaded performance, and 6% higher multi-threaded performance compared to Ivy Bridge. However, desktop variants drew between 8% and 23% more power under load and ran around 15 °C hotter. The integrated GPU saw up to a 20% performance increase (HD4600 vs HD4000). Haswell introduced new sockets and chipsets, including LGA 1150 for desktops and LGA 2011-v3 for enthusiast-class platforms with DDR4 support. The architecture's low-power C6 and C7 sleep states required compatible power supply units. Haswell-EP server variants, released in September 2014, offered up to 18 cores and up to 45 MB of last-level cache, with cluster on die (COD) operation mode for NUMA-aware systems. The Haswell-EX variant followed in May 2015 with functioning TSX. At least one Haswell-based processor, the Pentium G3420, was still being sold.
Did You Know?
- Haswell was the first Intel microarchitecture to feature a fully integrated voltage regulator (FIVR).
- The GT3e integrated graphics variant included on-package 128 MB of embedded DRAM called Crystalwell, serving as a Level 4 cache.
- Haswell-ULT and Haswell-ULX variants were only available in dual-core configurations due to low power requirements.
- A bug in the TSX implementation on Haswell, Haswell-E, Haswell-EP, and early Broadwell CPUs led to its disabling via microcode update in August 2014.
Frequently Asked Questions
What is Haswell (microarchitecture)?
Haswell is Intel's 2013 'tock' step in the Tick–Tock cadence, announced on June 4, 2013. It kept Ivy Bridge's 22 nm FinFET node but reworked the core design for better per-watt performance across the x86 and x86-64 instruction sets.
What processors and platforms did Haswell power?
The 4th-generation Core lineup, v3-suffixed Xeon server chips, and various Pentium and Celeron models all shared the Haswell core. Consumer parts landed on LGA 1150 (plus PGA/BGA for mobile), while Xeon v3 used LGA 2011-v3, with TDP spanning 10 W to 160 W.
Why is Haswell important to the x86 ecosystem?
It proved that a second generation on the same FinFET node could still deliver meaningful architectural gains—more execution units, a redesigned memory controller, and integrated GPU improvements—without waiting for a new process node. That 'tock' philosophy kept Intel competitive in 2013–2014 while the industry prepared for 14 nm.
What memory and I/O does Haswell support?
LGA 1150 variants provide dual-channel DDR3/DDR3L with up to 32 GB of RAM and 16 lanes of PCI Express 3.0. Server LGA 2011-v3 parts expanded on-channel memory and PCIe connectivity for multi-socket Xeon configurations.
