Bloomfield was the internal name Intel gave to its high-end desktop chips sold under the Core i7-9xx label, as well as to single-processor server chips sold as Xeon 35xx. These two product lines were nearly identical in design. Bloomfield took over from the earlier Yorkfield processors and was a close relative of the dual-processor Gainestown line—both share the same CPUID value (0106Ax, family 6, model 26) and use the same socket. Despite being built on the same 45 nm Nehalem microarchitecture as the later Lynnfield and Clarksfield processors, Bloomfield required a different socket, even though some of those later chips also carried the Core i7 name.
Bloomfield introduced several major changes compared to Yorkfield. It used a new LGA 1366 socket that was not backward-compatible with older processors. The memory controller moved onto the processor die itself, forming part of what Intel called the "uncore," which ran at its own clock speed separate from the execution cores. This controller supported three memory channels, each capable of handling up to two DDR3 DIMMs; motherboards typically offered three, four (in a 2-1-1 layout), or six DIMM slots. Only DDR3 memory was supported. The traditional front-side bus was replaced by Intel's QuickPath Interconnect, meaning motherboards needed a chipset that worked with that interface.
The cache layout was also new: each core had 32 kB of L1 instruction cache and 32 kB of L1 data cache, plus 256 kB of L2 cache (combined instruction and data). A shared 8 MB L3 cache (also combined, and "inclusive") was used by all cores. Unlike the multi-chip module approach of Yorkfield—which used two dual-core dies—Bloomfield was a single-die device containing all four cores, the memory controller, and all cache. Turbo Boost technology let active cores automatically increase their clock speed in 133 MHz steps above the rated speed, as long as thermal and electrical limits were not exceeded. Hyper-Threading returned after being absent from the Core architecture; with it enabled, each of the four physical cores could handle two threads, making the processor appear as eight logical CPUs to the operating system. Only one QuickPath interface was included, so the chip was not intended for multi-processor motherboards. The processor was built on a 45 nm process, contained 731 million transistors, and had a die size of 263 mm².
