Specific fan power
Parameter quantifying energy efficiency of fan air-movement systems.
Specific fan power (SFP) is a metric used to assess how efficiently a fan or group of fans moves air. It indicates the electrical power required to operate the fan(s) in relation to the total volume of air they move. The value of SFP for any given fan is not fixed; it varies depending on the airflow rate and the pressure the fan must overcome.
The formula for SFP at a specific operating point (defined by a particular flow rate and pressure rise) is the total electrical power consumption of the fan or system (in kilowatts) divided by the total airflow volume (in cubic meters per second). Different versions of SFP exist for various applications, such as SFPe for building energy performance, SFPv for verification testing, SFPi for an individual fan, SFPAHU for an air handling unit, SFPFCU for a fan coil unit, and SFPBLDG for an entire building. These sub-definitions also cover how to handle fans that run intermittently, like kitchen hoods, and how to account for part-load performance in variable air volume systems. SFP can be expressed in several equivalent SI units: kilowatts per cubic meter per second, watts per liter per second, kilojoules per cubic meter, or kilopascals.
Because pressure represents energy per cubic meter of air, SFP can be expressed in pressure units. The relationship between SFP, the total pressure rise across the fan, and the overall efficiency of the fan system is straightforward: the overall efficiency multiplied by SFP equals the total pressure rise. In a perfect, lossless system (100% efficiency), SFP would exactly match the fan’s pressure rise. In practice, overall fan system efficiency is often between 0% and 60%, with the lowest efficiencies occurring in small fans or at inefficient operating points such as throttled flow or free-flow conditions. This overall efficiency accounts for all losses in the system, including aerodynamic losses in the fan, friction in the drive (like a belt), losses in the electric motor, and losses in variable speed drive electronics.
- Definition
- SFP = ∑P / q_v, where ∑P is electrical power in kW and q_v is air flow in m³/s
- Equivalent units
- kW/(m³/s), W/(l/s), kJ/m³, kPa
- Ideal efficiency
- η_tot = 1 gives SFP equal to fan pressure rise
- Typical efficiency range
- 0 to 60% (η_tot < 0.6)
- Lowest efficiency conditions
- small fans or inefficient operating points (throttled flow or free-flow)
Lore & Background
SFP is defined for a given fan system and operating point as the ratio of total electrical power used to the gross air volume flow rate. Various sub-definitions exist for specific applications, including SFPe for building energy performance calculations, SFPv for performance verification tests, SFPi for individual fans, SFPAHU for air handling units, SFPFCU for fan coil units, and SFPBLDG for whole buildings. The source article notes that reference 1 describes how to account for intermittently operated fans, such as kitchen hoods, and part-load performance in variable air volume (VAV) systems.
Reader's Guide
SFP can be expressed in units of pressure, as pressure is a measure of energy per cubic meter of air. The relationship between SFP, fan pressure rise, and fan system efficiency is given by η_tot · SFP = Δp_t, where η_tot is the overall efficiency of the driven fan system and Δp_t is the rise in total pressure through the fan. In an ideal lossless fan system (η_tot = 1), SFP equals the fan pressure rise, which is the total pressure loss in the ventilation system. In reality, fan system efficiency is often in the range of 0 to 60%, being lowest for small fans or inefficient operating points such as throttled flow or free-flow. The efficiency depends on total losses in the fan system, including aerodynamic losses in the fan, friction losses in the drive (e.g., belt), losses in the electric motor, and variable speed drive power electronics. The source article directs readers to reference 1 for more insight into maximizing energy efficiency and minimizing noise in fan systems.
Did You Know?
- SFP is not constant for a given fan but changes with both air flow rate and fan pressure rise.
- SFP can be expressed in equivalent SI units including kW/(m³/s), W/(l/s), kJ/m³, and kPa.
- In an ideal lossless fan system (η_tot = 1), SFP is exactly equal to the fan pressure rise.
