A topographic map is a large-scale map that quantitatively represents relief features, often using contour lines to show equal elevation.[1] Such maps include accurate depictions of both natural and manmade features.[2] They are distinguished from smaller-scale chorographic maps, planimetric maps that lack elevation, and thematic maps focused on specific topics.[3]
Quick Facts
- Modern technique
- lidar and remote sensing
- Digital dataset examples
- TIGER and Digital Elevation Models (DEMs), developed in the 1980s
- Common alternative names
- contour maps
- topo maps
- quads or quadrangles (in the U.S.)
Facts from the source article.
Key facts and history
They are based on topographical surveys, which at large scales show a variety of elevations and landforms, unlike older cadastral surveys that primarily show property boundaries.[4] Military forces prepared topographic surveys to assist in battle planning and defensive emplacements, giving rise to the United Kingdom's Ordnance Survey.[5] Clarence King, the first Director of the U.S. Geological Survey, initially confined topographic mapping to what was necessary to support geologic studies.[6] Observations about terrain were recorded in some of the earliest maps.[7]
In 1789, the Carte géométrique de la France became the initial multi-sheet topographic map series covering an entire nation.[8] For military planning, data on elevation was critically important.[5] The United States Geological Survey, created in 1879, took over the national mapping responsibilities previously held by the Army Corps of Engineers and the Department of the Interior.[9] National topographic map series evolved into essential tools for infrastructure development and resource management.[9]
National mapping organizations differ greatly in the cartographic style of their topographic maps.[10] Medium-scale topographic maps from European nations often retain long-standing aesthetic conventions and traditions in their symbology.[10]
What the cited sources add
The Art & Architecture Thesaurus notes that topographic maps are classified within the hierarchy of cartographic materials as a type of map by form.[2] The same source distinguishes topographic maps from topographical views, which are visual works by subject type.[2]
