Serpentiles
Hexagonal tiles for edge-matching puzzle games.
Serpentiles is a term coined by Kurt N. Van Ness for hexagonal tiles used in edge-matching puzzle connection abstract strategy games, including Psyche-Paths, Kaliko, and Tantrix. On each tile, between one and three colors create paths that connect the six sides in different arrangements, with every side linked to another by a specific path route and color. During gameplay, players take turns placing tiles adjacent to existing ones so that colored paths remain continuous across tile edges. The name also applies to a single-player puzzle connection game created by Brett J. Gilbert and released by ThinkFun in 2008. That version uses square (1×1) and rectangular (2×1) tiles, along with challenge cards that list which tiles must be arranged to form a contiguous path.
Van Ness also devised a three-digit notation for tile categories based on the paths shown. In the notation xyz, x represents the number of paths linking sides with adjacency 3 (opposite sides, two segments apart), y the number linking sides with adjacency 2 (one segment apart), and z the number linking sides with adjacency 1 (adjacent sides, zero segments apart). Since there are six sides and three paths, the sum of the three digits always equals three. Van Ness published a mathematical description using the sum from n=1 to 3 of 10^(n−1) * a_n, where a_n is the count of segments with adjacency n. Ignoring path color, there are five distinct combinations of six sides and three paths.
A hexagon with flat sides left and right can be rotated orthogonally in 60° increments, giving six possible rotational positions. The tile 300 has rotational symmetry: any 60° rotation leaves the same sides linked, so it has one unique rotational position. The tile 003 has two unique rotational positions—one 60° rotation links different sides, but a second rotation returns to the original linkage. Tiles 102 and 120 each have three unique rotational positions, and 021 has six.
To describe each rotational position uniquely, a reference frame numbers the sides from 1 to 6 sequentially anti-clockwise. Paths connecting sides are described as linked pairs. For example, for 003, starting from the lower right edge and moving anti-clockwise, the pair notation is 12-34-56. Rotating the tile 60° anti-clockwise adds 1 to each number (modulo 6), changing the pairs to 23-45-61. The order within a pair and the order of pairs do not m
- coined_by
- Kurt N. Van Ness
- field
- Abstract strategy games, puzzle design
- known_for
- Hexagonal edge-matching tiles and three-digit notation for tile categories
- related_games
- Psyche-Paths, Kaliko, Tantrix
- single_player_game
- Serpentiles (2008) by Brett J. Gilbert, published by ThinkFun
Lore & Background
Kurt N. Van Ness coined the name Serpentiles for hexagonal tiles used in edge-matching puzzle connection abstract strategy games. He also devised a three-digit notation (xyz) to categorize tiles based on the number of paths linking sides with adjacency 3 (opposite sides), adjacency 2 (one segment apart), and adjacency 1 (adjacent sides). The sum of the digits is always three, as there are three paths between six sides. Van Ness published a mathematical description using a sum formula where each digit corresponds to the count of segments with a given adjacency.
Reader's Guide
The Serpentiles notation provides a systematic way to classify hexagonal tiles by path configurations, with five distinct combinations of six sides and three paths. Rotational symmetry varies among tile types: 300 has one unique rotational position, 003 has two, 102 and 120 have three, and 021 has six. The notation can be extended to square tiles (two-digit yz) and octagonal tiles (four-digit wxyz), though for octagons the notation does not uniquely describe the path configuration, requiring additional rotational position notation. The square tiles lacking rotational symmetry are known as Truchet tiles, described by Sébastien Truchet in 1704 and popularized by Cyril Stanley Smith in 1987. Octagonal tiles can be combined with square tiles rotated 45° to tile a surface with paths across all edges.
Did You Know?
- The three-digit notation xyz for Serpentiles tiles sums to three because there are three paths between six sides.
- Square Serpentiles tiles are sometimes confused with Truchet tiles, but Truchet tiles are specifically square tiles divided by a diagonal line into two colored halves, as described by Sébastien Truchet in 1704.
- Octagonal tiles are not part of the established canon for Serpentiles; the notation and claimed duplicates for octagonal tiles are unsupported and likely invented.
