Underclocking
Reducing clock rate to lower power, heat, and noise.
Underclocking, or downclocking, involves adjusting a computer or electronic circuit’s timing so it operates at a slower clock speed than the manufacturer’s default. This technique is used to cut power usage, extend battery life, lower heat output, and can also boost system stability, longevity, reliability, and compatibility. It is the direct opposite of overclocking. While some devices come underclocked from the factory, many computers and components allow users to do it themselves.
**CPU underclocking** For microprocessors, the main goal is usually to reduce the need for heat sinks or fans, or to lower electrical consumption. This can improve stability in hot environments or let a system run with quieter, slower fans—or even no fan at all. For instance, a Pentium 4 processor normally set at 3.4 GHz can be dropped to 2 GHz and safely used with reduced fan speeds. The trade-off is a loss in system performance, though the performance drop is often proportionally smaller than the clock-speed reduction because other bottlenecks (like the hard drive, GPU, disk controller, or network) limit overall speed. Underclocking specifically refers to changing the timing of a synchronous circuit to lower energy needs. Deliberately limiting a processor’s speed may affect how fast tasks complete, but whether the slowdown is noticeable depends on the rest of the hardware and the intended use.
Many computers and devices offer underclocking options. Manufacturers include them for various reasons: to manage excessive heat (since lower performance generates less heat inside the device) and to reduce the energy required to run it. Laptops and other battery-powered devices often have underclocking settings to prolong time between charges. Beyond providing these features, manufacturers may also limit a machine’s capability to improve efficiency. Reduced instruction set computer (RISC) designs, for example, help create devices that consume less power.
**Graphics cards** Graphics cards can also be underclocked, typically to cut heat output. A GPU can be set to run at lower clock speeds during everyday tasks like web browsing or word processing, which keeps temperatures down and allows quieter, slower fan operation. For graphically demanding applications such as games, the GPU can then be overclocked.
- Power reduction example
- Underclocking an Athlon XP 1700+ from 1466 to 1000 MHz and reducing voltage from 1.75 to 1.15V reduced power consumption from 64.0 to 21.6W (66% reduction) with 26% less performance.
- Power reduction example 2
- A single-core Intel CPU underclocked by 20% showed a 13% performance decrease and a 49% power reduction.
- Asus eee pc underclock
- Earlier models used a 900 MHz Intel Celeron M processor underclocked to 630 MHz.
Lore & Background
Underclocking can be applied to CPUs, GPUs, and memory. For microprocessors, the purpose is generally to decrease the need for heat dissipation or reduce electrical power consumption, allowing quieter cooling or fanless operation. Graphics cards can be underclocked to reduce heat output and fan noise during everyday tasks, then overclocked for intensive applications. Memory underclocking is used to match older systems or improve stability with mixed-speed modules. Dynamic frequency scaling, a form of automatic underclocking, is common on laptops and has become common on desktops. Technologies such as AMD's Cool'n'Quiet and PowerNow! and Intel's SpeedStep automatically underclock under light loads. Some processors also underclock defensively to prevent overheating. Underclocking competitions exist, similar to overclocking competitions but aiming for the lowest clock speed.
Reader's Guide
Underclocking's significance lies in its ability to trade raw performance for efficiency, stability, and reduced noise. It is widely used in laptops and mobile devices to extend battery life, often through automatic dynamic frequency scaling. The practice demonstrates that full processor power is rarely needed for typical desktop use, as performance bottlenecks from memory, disk, and other devices mean that underclocking often yields a smaller performance loss than the clock reduction would suggest. Underclocking also enables quieter operation by allowing slower fan speeds or fanless designs. In mobile devices like smartphones and PDAs, designers often choose a more powerful processor underclocked rather than a slower processor at full speed, because the more powerful processor can offer better performance per watt. Underclocking can be performed manually in the BIOS, through operating system tools (such as Linux's cpufreq governors or Windows power management settings), or via EFI on Mac systems. It remains a practical technique for reducing heat in high-temperature environments, extending hardware lifespan, and improving compatibility with older software that depends on CPU timing.
Did You Know?
- Underclocking a Pentium 4 from 3.4 GHz to 2 GHz can allow safe operation with reduced fan speeds.
- The Linux kernel includes six cpufreq governors: Conservative, Ondemand, Performance, Powersave, Userspace, and Schedutil.
- Underclocking a GPU for everyday tasks like web browsing allows quieter fan speeds, with performance loss noticeable only in graphically intensive applications.
- Some processors underclock automatically as a defensive measure to prevent permanent damage from overheating.
