EDM4S
Portable anti-drone jammer developed by Lithuanian company NT Service.
The EDM4S SkyWiper, or Electronic Drone Mitigation 4 - System, is a portable anti-drone device made by the Lithuanian firm NT Service. It uses an electromagnetic pulse to jam the communications and satellite navigation of small to medium UAVs.
NT Service, based in Kaunas, first showed the device at the 2019 Security and Counter Terror Exhibition in London. The company also produces it with the Israeli firm Skylock under the name "Skybeam."
One person can carry the device. The operator aims it at a UAV and activates it to block the drone’s communications out to 3–5 km (2–3 mi), along with its satellite navigation. Depending on how autonomous the UAV is, it may drop from the sky, land in a controlled way, go back to an earlier waypoint, or keep flying normally.
The device comes with either 4 or 6 antennas. The standard setup includes two antennas for the 2.4 GHz and 5.8 GHz bands (10 W each), one for the GPS 1.5 GHz band (10 W), and one for the GLONASS 1.5 GHz band (10 W). It is made of aluminum, and the "gun" part is modeled after the Heckler & Koch G36 rifle, with a trigger to activate it and optics for aiming. It weighs 5.5 kg and measures 1050 × 220 × 360 mm with the stock extended (830 × 220 × 360 mm without). A 24 V battery powers it for up to 60 minutes.
The EDM4S-UA version, costing US$15,000 per unit, was first used by the Ukrainian Armed Forces against Russian separatist drones in Donbas in 2021 during the Russo-Ukrainian War. It has since been used in the Russian invasion of Ukraine, neutralizing drones like the Eleron-3. In June 2022, Lithuania donated 110 units to Ukraine for €1.5 million (US$1.56 million).
Current operators include the Lithuanian Armed Forces, the Ukrainian Armed Forces (EDM4S-UA), the Romanian Armed Forces (Skylock Skybeam), and the Nigerian Armed Forces (EDM4S SkyWiper).
Quick Facts
- Origin
- Lithuania
- Service
- 2021–present
- Wars
- Russo-Ukrainian War
- Designer
- NT Service UAB
- Design Date
- c. 2018
- Unit Cost
- around $15,000
- Variants
- EDM4S-UA / Skylock Skybeam
- Mass
- 5.5 kg
- Length
- 1050 mm
- Height
- 360 mm
- Is Ranged
- yes
- Range
- 3 -
Facts from the source article.
Lore & Background
The EDM4S was first shown by NT Service, based in Kaunas, Lithuania, at the 2019 Security and Counter Terror Exhibition in London. In partnership with Israeli company Skylock, NT Service also produces the system under the name 'Skybeam.' The device is carried by one person and operated by pointing it at a UAV and activating it to disrupt communications and satellite navigation. Depending on the UAV's level of autonomy, it may fall out of the sky, make a controlled landing, return to an earlier waypoint, or continue operating normally.
The device can have 4 or 6 antennas. By default there are two antennas for the 2.4 GHz and 5.8 GHz frequency bands (10 W each), one antenna for the GPS 1.5 GHz band (10 W), and one antenna for the GLONASS 1.5 GHz band (10 W). It is made of aluminium, with the 'gun' portion modelled after the Heckler & Koch G36 rifle, including a trigger and optics for sighting. It is powered by a 24 V battery lasting up to 60 minutes.
The EDM4S-UA version was first used by the Ukrainian Armed Forces against Russian separatist drones in Donbas in 2021 as part of the Russo-Ukrainian War. It has since seen further use in the Russian invasion of Ukraine, neutralizing drones such as the Eleron-3. In June 2022, Lithuania donated 110 units to Ukraine at a cost of €1.5 million (US$1.56 million). Current operators include the Lithuanian Armed Forces, Ukrainian Armed Forces (EDM4S-UA), Romanian Armed Forces (Skylock Skybeam), and Nigerian Armed Forces (EDM4S SkyWiper).
Reader's Guide
The EDM4S is notable as a portable, man-portable electronic warfare system specifically designed to counter small and medium UAVs, a growing threat in modern conflicts. Its development by a Lithuanian company and partnership with an Israeli firm highlights international collaboration in drone countermeasures. The device's use in the Russo-Ukrainian War, first against separatist drones in Donbas in 2021 and later during the full-scale invasion, demonstrates its operational relevance. The donation of 110 units by Lithuania to Ukraine in June 2022 at a cost of €1.5 million underscores its perceived value in real-world combat. The EDM4S's design, modelled after a rifle, and its ability to jam multiple frequency bands (2.4 GHz, 5.8 GHz, GPS, GLONASS) reflect a tailored approach to disrupting common drone communication and navigation systems. Its adoption by armed forces in Lithuania, Ukraine, Romania, and Nigeria indicates a growing market for such portable anti-drone systems.
Did You Know?
- The EDM4S is also produced under the name 'Skybeam' in partnership with Israeli company Skylock.
- The device's 'gun' portion is modelled after the Heckler & Koch G36 rifle.
- It can have 4 or 6 antennas, with default antennas for 2.4 GHz, 5.8 GHz, GPS, and GLONASS bands.
