CASIC WJ

Lore & Background

The WJ-010 is an armed development of the unarmed CASIC HW-100 Sparrowhawk, sharing its layout. It uses a modular design to rapidly swap between an optical reconnaissance payload and a warhead, allowing it to function as either a scout or a suicide attack UAV. The WJ-100 Blade (Dao-Feng) is the latest model of the Blade series as of early 2015, sharing a twin-boom layout, high wing configuration, and tricycle landing gear with other Blade series members such as the CASIC HW-300 and CASIC SF-460. Its winglets are larger than those of earlier Blade models, and it is powered by a two-blade propeller driven by a pusher engine mounted at the rear of the fuselage.

The WJ-500 is a jet-powered UAV intended for targeting, reconnaissance, target damage assessment, and simulation of cruise missiles and aircraft. It has a cylindrical fuselage with an inlet atop the empennage and can be fitted with wing tip tanks on the main wing. It made its public debut in November 2014 at the 10th Zhuhai Airshow. The WJ-600 A/D is a development of the CASIC HW-610 and CASIC HW-600 Sky Hawk (WJ-600), combining reconnaissance and ground attack capabilities in a single platform, with its name A/D standing for attack drone. Two WJ-600 A/Ds were spotted in a military parade in Turkmenistan on 27 October 2016, marking the first confirmed export.

The WJ-700, unveiled at the 2018 Zhuhai Airshow, is a medium-/high-altitude long-endurance (MALE/HALE) armed reconnaissance UAV with a maximum takeoff weight of 3,500 kg and an endurance of up to 20 hours. It has four underwing hardpoints and can carry CM-102 anti-radiation missiles, C-701 and C-705KD anti-ship missiles, and land attack munitions.

Reader's Guide

The CASIC WJ series represents a significant evolution in Chinese UAV development, showcasing modular design, multi-role capability, and export success. The WJ-010's ability to switch between reconnaissance and suicide attack roles via a modular payload highlights a flexible approach to battlefield requirements. The WJ-100 Blade continues the twin-boom layout tradition of the Blade series, with incremental improvements such as larger winglets. The WJ-500 introduces jet propulsion for higher-speed missions like target simulation and damage assessment, debuting at the 2014 Zhuhai Airshow. The WJ-600 A/D merges the reconnaissance and ground attack functions of its predecessors into a single platform, achieving export confirmation in Turkmenistan in 2016. The WJ-700, with its MALE/HALE capabilities, heavy payload capacity, and anti-ship and anti-radiation missile armament, demonstrates a move toward larger, more capable armed reconnaissance UAVs. The series as a whole reflects CASIC's focus on integrating diverse mission profiles—from suicide attack to high-speed target simulation to long-endurance strike—into a coherent family of unmanned systems.

Did You Know?

• The WJ-010 is an armed version of the unarmed CASIC HW-100 Sparrowhawk and shares its layout.
• The WJ-100 Blade is also known as Dao-Feng or Daofeng (刀锋).
