Pteryx UAV
Polish civilian UAV for photomapping with autonomous and RC operation.
Last updated
Kbosak · CC BY 3.0
The Pteryx UAV is a Polish miniature unmanned aerial vehicle (UAV) designed for civilian use, manufactured and sold by Trigger Composites. It functions both as a flying remote control model and a pre-programmed vehicle, and was awarded the Innowator Podkarpacia medal for innovative design in the micro-enterprises category of the Podkarpacie region in 2010.
Background
The Pteryx UAV was developed by Trigger Composites and uses a custom derivation of the FLEXIPILOT software designed by the Aerial Robotics engineering group for photomapping and civilian use. Its avionics and flying platform are capable of full operational capability without an active transmitter or ground station. The aircraft is constructed from custom fiberglass composite material covered with durable red gelcoat, with carbon fiber and Kevlar reinforcements, wood, and other plastics; wooden or all-composite wings are offered.
The UAV can be launched by catapult and lands via parachute. It carries a fully enclosed camera head that can be mounted for nadir or oblique photography, and the entire head can be tilted in flight using the RC transmitter. The camera mount accommodates a pre-installed compact digital camera or can be exchanged for other equipment, supporting a payload weight range of 200 g to 1000 g. The aircraft provides positions for photos taken and has storage for 8000 events.
Multiple missions per day can be flown without reprogramming the autopilot, using waypoints. The system features single-button operation and an exchangeable mission package. Assembly time is around five minutes.
Did You Know?
- It can fly up to 120 minutes with a 450 g payload or 55 minutes with a 1 kg payload.
- Data processing options include using free 3D modelling services or a pre-paid cloud computing service that delivers results in hours.
Frequently Asked Questions
Who builds the Pteryx UAV and where does it come from?
The Pteryx UAV is a Polish miniature unmanned aerial vehicle produced by Trigger Composites. It was developed as a civilian platform rather than a military system, targeting the micro-enterprise sector in the Podkarpacie region of southeastern Poland.
What are the Pteryx UAV's key flight specifications?
It has a 2.8 m wingspan, 1.4 m length, and 0.33 m height, with a maximum takeoff weight of 5.0 kg. Endurance reaches roughly 55 minutes carrying a 1 kg payload or up to 120 minutes with a lighter 450 g payload.
How do the Pteryx Lite and Pteryx Pro variants differ?
The two versions are distinguished mainly by their service ceiling: the Pteryx Lite is rated to 3,000 m, while the Pteryx Pro is limited to 1,200 m. Both share the same airframe dimensions and payload endurance figures.
What recognition has the Pteryx UAV earned?
In 2010 it received the Innowator Podkarpacia medal, an award honoring innovative design among micro-enterprises in the Podkarpacie region. The recognition highlighted its compact, dual-mode flight architecture as a notable achievement for a small Polish manufacturer.
