Freeze drying
Low-temperature dehydration preserving original qualities via sublimation.
Freeze drying, also known as lyophilization or cryodesiccation, is a low-temperature dehydration process that involves freezing the product and lowering pressure, thereby removing ice by sublimation. This method contrasts with conventional dehydration that uses heat, and because of the low temperatures, the rehydrated product retains many of its original qualities. When solid objects such as strawberries are freeze dried, their original shape is maintained. For liquid products, often used in pharmaceuticals, the final properties are optimized through the addition of excipients, or inactive ingredients. Primary applications include biological materials like bacteria and yeasts, biomedical items such as surgical transplants, and food processing and preservation, including coffee.
The history of freeze drying stretches back centuries. The Inca freeze dried potatoes into chuño as early as the 13th century by exposing them to freezing temperatures on Andean mountain peaks at night, then squeezing out water and drying them in sunlight during the day. They also used the Altiplano’s climate to freeze dry meat. In Japan, koya-dofu, or freeze-dried tofu, dates to the mid-1500s in Nagano and the 1600s on Mount Koya. These methods, however, are not technically equivalent to the modern process, which requires refrigeration and vacuum systems. Modern freeze drying began in 1890 with Richard Altmann, who devised a method to freeze dry tissues, though it went largely unnoticed until the 1930s. In 1909, L. F. Shackell independently created a vacuum chamber using an electrical pump. Further developments came with Tival in 1927 and Elser in 1934, who patented systems with improved freezing and condenser steps. A major turning point occurred during World War II, when freeze drying was developed commercially to stabilize blood plasma and penicillin for field treatment without refrigeration. In the 1950s and 1960s, it became a multi-purpose tool for pharmaceuticals and food processing. In 2020, freeze dried candy surged in popularity due to social media, with versions of Skittles, Nerd Gummy Clusters, and SweeTarts appearing in stores.
Freeze-dried foods became a key component of astronaut and military rations. Early astronaut meals were tubed or freeze-dried snacks that were difficult to rehydrate, but improvements allowed hot meals. NASA addressed crumb problems with a gelati
- field
- Dehydration technology
- known_for
- Low-temperature dehydration via sublimation; preservation of biological and food products without refrigeration
- earliest_known_use
- 13th century (Inca freeze drying potatoes into chuño)
- modern_development_began
- 1890 (Richard Altmann)
- key_wartime_application
- World War II (blood plasma and penicillin)
Lore & Background
Freeze drying has ancient roots: the Inca were freeze drying potatoes into chuño since the 13th century, using cycles of freezing on mountain peaks and squeezing out water in sunlight. The Japanese also produced koya-dofu, freeze-dried tofu, dating to the mid-1500s in Nagano and the 1600s on Mount Koya. These methods are similar but not technically equivalent to the modern process, which requires refrigeration and vacuum systems.
Modern freeze drying began as early as 1890 when Richard Altmann devised a method to freeze dry tissues, though it went virtually unnoticed until the 1930s. In 1909, L. F. Shackell independently created the vacuum chamber using an electrical pump. Further developments came with patents by Tival in 1927 and Elser in 1934, improving freezing and condenser steps.
A significant turning point occurred during World War II, when freeze drying enabled blood plasma and penicillin to be rendered chemically stable and viable without refrigeration, solving the problem of spoilage during transport. In the 1950s–1960s, freeze drying became a multi-purpose tool for both pharmaceuticals and food processing. In 2020, freeze dried candy saw a major surge in popularity due to viral social media trends.
Reader's Guide
Freeze drying's significance lies in its ability to preserve materials—from biological samples to food—without the damage caused by heat. During World War II, it solved the critical problem of transporting blood plasma and penicillin without refrigeration, saving countless lives. The process has four stages: pretreatment, freezing, primary drying, and secondary drying. In primary drying, about 95% of water is removed by sublimation under vacuum; secondary drying removes unfrozen water molecules. The method retains the original shape of solid objects like strawberries and, for liquids, allows optimization via excipients. Freeze-dried foods became a major component of astronaut and military rations, with innovations such as gelatin coating to prevent crumbs and algae-based oils to add polyunsaturated fatty acids. The development of the Hazard Analysis and Critical Control Points (HACCP) plan further improved safety. The technique remains essential in pharmaceuticals, food preservation, and space travel, offering long shelf life and stability without refrigeration.
Did You Know?
- The Inca freeze dried potatoes into chuño since the 13th century using mountain peak freezing and sunlight drying.
- Japanese koya-dofu, freeze-dried tofu, dates to the mid-1500s in Nagano and the 1600s on Mount Koya.
- During World War II, freeze drying enabled blood plasma and penicillin to be chemically stable without refrigeration.
- In 2020, freeze dried candy surged in popularity due to viral social media trends.
