Aperture masking interferometry
A speckle interferometry technique achieving diffraction-limited imaging via aperture masks.
Aperture masking interferometry (also known as sparse aperture masking) is a form of speckle interferometry that allows diffraction-limited imaging from ground-based telescopes such as the Keck Telescope and the Very Large Telescope. It is also a high-contrast imaging mode on the James Webb Space Telescope. The technique enables ground-based telescopes to reach the maximum possible resolution, allowing large-diameter ground-based telescopes to produce far greater resolution than the Hubble Space Telescope.
- Developed by
- John E. Baldwin and collaborators in the Cavendish Astrophysics Group at the University of Cambridge
- Development period
- late 1980s
- Ground based telescopes using it
- Keck Telescope, Very Large Telescope
- Space telescope using it
- James Webb Space Telescope
- Number of holes in jwst mask
- 7
- Instrument on jwst
- NIRISS
Lore & Background
In aperture masking, a mask is placed over the telescope that only allows light through a small number of holes, acting as a miniature astronomical interferometer. The bispectral analysis (speckle masking) method is typically applied to image data taken through masked apertures, where most of the aperture is blocked off. The aperture mask removes atmospheric noise through the use of closure quantities, allowing the bispectrum to be measured more quickly than for an un-masked aperture. Masks are usually placed either in front of the secondary mirror or in a re-imaged aperture plane. They are categorized as non-redundant or partially redundant. Non-redundant masks consist of arrays of small holes where no two pairs of holes have the same separation vector, providing a set of fringes at a unique spatial frequency in the image plane. Partially redundant masks provide a compromise between minimizing redundancy and maximizing throughput and the range of spatial frequencies investigated.
Reader's Guide
The principal limitation of aperture masking interferometry is that it is applicable only to relatively bright astronomical objects, since the mask discards most of the light received from the source. Although the signal-to-noise of speckle masking observations at high light level can be improved with aperture masks, the faintest limiting magnitude cannot be significantly improved for photon-noise limited detectors. On the James Webb Space Telescope, aperture masking interferometry is the first execution of this technique (or any form of interferometry) in space, enabled by a non-redundant mask with seven holes embedded as a mode of the NIRISS instrument. The technique allows ground-based telescopes to reach the maximum possible resolution, allowing ground-based telescopes with large diameters to produce far greater resolution than the Hubble Space Telescope.
Did You Know?
- The technique was developed by John E. Baldwin and collaborators in the Cavendish Astrophysics Group at the University of Cambridge in the late 1980s.
- Aperture masking interferometry is available on the James Webb Space Telescope as a mode of the NIRISS instrument.
- The mask discards most of the light, limiting the technique to relatively bright astronomical objects.
Frequently Asked Questions
Who created Aperture masking interferometry?
The technique was developed in the late 1980s by John E. Baldwin and his collaborators within the Cavendish Astrophysics Group at the University of Cambridge.
What is Aperture masking interferometry's core function?
It is a speckle-interferometry method that places sparse masks over a telescope's aperture to extract diffraction-limited images, effectively letting ground-based instruments reach their theoretical maximum resolving power.
Which telescopes feature Aperture masking interferometry?
The Keck Telescope and the Very Large Telescope both employ it on the ground, while the James Webb Space Telescope carries it as a high-contrast imaging mode on its NIRISS instrument.
Why does Aperture masking interferometry matter in astrophotography?
By pushing ground-based observatories to their full diffraction limit, it lets large-diameter facilities like Keck and VLT achieve angular resolution well beyond what the Hubble Space Telescope can deliver.
How does Aperture masking interferometry work on the James Webb Space Telescope?
On JWST's NIRISS instrument the technique uses a mask with seven precisely placed holes to modulate the incoming light, enabling high-contrast, diffraction-limited observations of faint targets near bright sources.
