Polarizer
An optical filter that transmits light of a specific polarization and blocks others.
Last updated
Reinraum · Public domain
Light waves of a particular polarization are allowed through an optical filter called a polarizer, while those of other polarizations are blocked.[1] Such a device takes a beam whose polarization is mixed or not defined and transforms it into one with a well-defined polarization state.[1]
Quick Facts
- Field
- Optics
- Types
- Linear polarizers and circular polarizers
Facts from the source article.
Key facts and history
These films can be mounted on a plate or cemented into a cube, such as the MacNeille cube.[2] Wire-grid polarizers reflect waves whose electric field is parallel to the wires, while transmitting waves with perpendicular electric fields.[3] A quarter-wave plate made of birefringent material can create circularly polarized light by delaying one component of the light relative to the other.[4] Thin glass plates, no thicker than 0.5 mm, containing elongated silver nano-particles, form a modern type of absorptive polarizer.[5]
These glass-based polarizers can have polarization ratios up to 100,000:1 and absorb only 1.5% of correctly polarized light.[5] Beam-splitting polarizers can be made by applying a special optical coating onto a glass substrate, creating a thin-film linear polarizer.[2] The electric field of the transmitted wave is oriented entirely perpendicular to the wires, resulting in linear polarization.[3]
What the cited sources add
Their analysis showed that for electric field components perpendicular to the wires, the medium behaves like a dielectric.[6] For electric field components parallel to the wires, the medium behaves like a reflective metal.[6] X. J. Yu and Hoi Sing Kwok, in a 2003 Journal of Applied Physics paper, used rigorous coupled-wave analysis to derive analytical solutions for wire-grid polarizers when light strikes at oblique angles.[7][6]
