GeForce 200 series
Second-generation Tesla architecture with unified shaders and double precision.
The GeForce 200 series is a line of graphics processing units from Nvidia built on the Tesla architecture. These chips represent the second generation of Nvidia's unified shader design, marking the first significant overhaul since the GeForce 8 series.
The GTX 280 and GTX 260 share the same processor core. During manufacturing, chips were tested and sorted by defect testing of core logic. Those that failed to meet the GTX 280's specifications were retested and binned as GTX 260 models, which have fewer stream processors, fewer ROPs, and a narrower memory bus. In late 2008, Nvidia released a revised GTX 260 with 216 stream processors instead of the original 192, creating two distinct GTX 260 cards with noticeable performance differences.
The GT200a and GT200b GPUs in the GeForce 200 series (excluding the GTS 250 and GTS 240, which use older G92b chips) support double precision for GPGPU tasks. They also deliver better geometry shading performance. The GT200 die contains 1.4 billion transistors on a 576 mm² surface, built on a 65 nm process. It ranks as the seventh largest commercial GPU ever made and the fifth largest CMOS-logic chip fabricated at TSMC. While the GeForce 400 series surpassed the GT200 in transistor count, the original GT200 die remains larger than the GF100 die. It is also bigger than the Kepler-based GK210 GPU in the Tesla K80, which has 7.1 billion transistors on a 561 mm² die at 28 nm. The Ampere GA100 is currently the largest commercial GPU, at 826 mm² with 54.2 billion transistors.
On October 12, 2009, Nvidia announced and released the GeForce 210 (GT218 GPU) and GeForce GT 220 (GT216 GPU), which were previously OEM-only. The GeForce GT 240 (GT215 GPU) followed on November 17, 2009. These 40 nm GPUs include the new PureVideo HD VP4 decoder hardware, whereas older GeForce 8 and 9 series chips only had VP2 or VP3 (G98). They also support Compute Capability 1.2, compared to the 1.1 support in earlier GeForce 8 and 9 cards. All GT21x GPUs contain an integrated audio processor and support eight-channel LPCM output over HDMI.
All models in the GeForce 200 series support Coverage Sample Anti-Aliasing, Angle-Independent Anisotropic Filtering, and 240-bit OpenEXR HDR. Compute Capability varies: 1.1 for the G92-based GTS 250, 1.2 for GT215, GT216, and GT218 GPUs, and 1.3 (with double precision) for GT200a and GT200b GPUs only.
