Clutter may be caused by man-made objects such as buildings and intentionally by radar countermeasures like chaff. Natural causes include terrain features, sea, precipitation, hail spike, dust storms, birds, turbulence in atmospheric circulation, and meteor trails. Radar clutter can also be caused by atmospheric phenomena such as disturbances in the ionosphere from geomagnetic storms or other space weather events, especially near the geomagnetic poles where solar wind action on the magnetosphere produces convection patterns in ionospheric plasma. This clutter can degrade the ability of over-the-horizon radar to detect targets. Clutter may also originate from multipath echoes from valid targets caused by ground reflection, atmospheric ducting, or ionospheric reflection/refraction (anomalous propagation), which is especially bothersome because it appears to move and behave like common targets such as aircraft or weather balloons.

Volume clutter, such as rain, hail, snow, and chaff, presents problems because the illuminated volume may not be completely filled, and scatterers may not be uniformly distributed. For example, a beam 10° in elevation at a range of 10 km could cover from ground level to 1750 meters, with rain at ground level but the top of the beam above cloud level. The rainfall rate will not be constant within the beam, so any assessment of clutter and signal-to-clutter ratio is only an estimate to the nearest 5 or 10 dB. Surface clutter return depends on the nature of the surface, its roughness, grazing angle, frequency, and polarization. The reflected signal is the phasor sum of many individual returns from sources both moving (leaves, rain drops, ripples) and stationary (pylons, buildings, tree trunks). Individual samples of clutter vary spatially from one resolution cell to another and temporally for a given cell.

Clutter folding is a term describing clutter seen by radar systems when the range extent of the clutter exceeds the pulse repetition frequency interval, preventing adequate clutter suppression and causing the clutter to 'fold' back in range. The solution is to add fill pulses to each coherent dwell, increasing the range over which clutter suppression is applied, but this degrades performance due to wasted transmitter power and a longer dwell time.
