Artificial dielectrics
Fabricated composites mimicking dielectrics for microwave manipulation.
Artificial dielectrics are engineered composite materials, typically made by embedding conductive shapes or particles within a nonconductive supporting material, to produce electromagnetic behavior that mimics natural dielectrics. Provided the spacing between these elements is less than the wavelength of the radiation, the material can refract and diffract electromagnetic waves, enabling its use in microwave devices such as lenses, diffraction gratings, mirrors, and polarizers. These materials form a direct historical link to metamaterials.
The concept emerged from the need for lightweight, low-loss structures for large microwave components, particularly in radar systems developed between the 1940s and 1970s. The term "artificial dielectrics" was coined by Winston E. Kock in 1948 while at Bell Laboratories, describing human-made materials of practical size that imitate the electromagnetic response of natural dielectric solids. Unlike natural dielectrics, where atoms or molecules provide the scattering response, artificial dielectrics use larger, human-constructed scatterers. These scatterers can be arranged in regular lattices, irregular lattices, random mixtures, or non-uniform concentrations.
In natural dielectrics, an applied electromagnetic field causes scattering at the atomic or molecular level, and the material’s macroscopic behavior is described by permittivity and permeability. For this description to be valid, the scatterers must have some spatial ordering, and the wavelength must be longer than the spacing between them. Artificial dielectrics replicate this by using larger, accessible scatterers—such as spheres, disks, or conducting strips—that respond to fields like atoms do, allowing a synthesized macroscopic response. This became feasible at radio and microwave frequencies in the late 1940s.
One specific type is the rodded medium, also known as a wire mesh or wire grid, consisting of a square lattice of thin parallel wires. Initial research on this medium was conducted by J. Brown, K.E. Golden, and W. Rotman.
- Originator
- Winston E. Kock
- Year originated
- 1948
- First use period
- 1940s and 1950s
- Primary frequency range
- microwave
- Associated technology
- radar microwave technologies
- Example structure
- rodded medium (wire mesh, wire grid)
Lore & Background
Artificial dielectrics were first conceptualized, constructed, and deployed for interaction in the microwave frequency range in the 1940s and 1950s. The term 'artificial dielectrics' was originated by Winston E. Kock in 1948 while he was employed by Bell Laboratories. It described materials of practical dimensions that imitated the electromagnetic response of natural dielectric solids. The artificial dielectrics were borne out of a need for lightweight low loss materials for large and otherwise heavy devices.
Natural dielectrics serve as a model for artificial dielectrics. When an electromagnetic field is applied to a natural dielectric, local responses and scattering occur on the atomic or molecular level. The macroscopic response is described as electric permittivity and magnetic permeability. For this macroscopic response to be valid, a type of spatial ordering must be present between the scatterers, and the applied field must be longer in wavelength than the lattice spacing. In the late 1940s, in the domain of long wavelengths such as radio frequencies and microwaves, it became possible to manufacture larger scale scatterers that mimic the local response of natural materials. The scattering elements are designed to scatter the electromagnetic field in a prescribed manner; their geometric shape—spheres, disks, conducting strips, etc.—contribute to the design parameters.
Some artificial dielectrics may consist of irregular lattices, random mixtures, or a non-uniform concentration of particles. The constructed medium has an effective permittivity and effective permeability, as intended. The rodded medium (also known as the wire mesh or wire grid) is a square lattice of thin parallel wires; initial research on this medium was conducted by J. Brown, K.E. Golden, and W. Rotman.
Reader's Guide
Artificial dielectrics are significant as a direct historical link to metamaterials. They came into use with the radar microwave technologies developed between the 1940s and 1970s. The term 'artificial dielectrics' came into use because these are macroscopic analogues of naturally occurring dielectrics; the difference is that the atoms or molecules are artificially (human) constructed materials. They were proposed because of the need for lightweight structures and components for various microwave delivery devices. The legacy of artificial dielectrics includes their role in enabling practical microwave lenses, diffraction gratings, mirrors, and polarizers. Their development demonstrated that macroscopic scatterers could be engineered to produce a desired effective permittivity and permeability, a principle that later informed the field of metamaterials. The rodded medium, or plasma medium, exemplifies early work in simulating plasma behavior with artificial structures. Further research explored applications such as the Luneburg lens for radio astronomy, where a lens constructed of uniform spherical shells seemed feasible. The foundational work by Kock, Brown, Golden, Rotman, and others established the principles that continue to influence engineered electromagnetic materials.
