Geoid
The geoid is the irregular equipotential surface of Earth's gravity.
The geoid is the shape that the ocean surface would take under the influence of Earth's gravity and rotation, absent winds and tides. It is a smooth but irregular surface, first described by Carl Friedrich Gauss as the 'mathematical figure of the Earth,' resulting from uneven mass distribution within and on Earth. This surface is extended across continents, as if by very narrow hypothetical canals, and can only be determined through extensive gravitational measurements and calculations. Although the concept has been important in geodesy and geophysics for almost 200 years, it was not precisely defined until the advent of satellite geodesy in the mid-20th century. Mathematician Gladys West was the first to synthesize a high-fidelity geoid from satellite data. The geoid is an essential component of satellite-based global positioning systems and serves as a reference coordinate surface for vertical coordinates such as orthometric heights, geopotential heights, and dynamic heights.
All points on the geoid share the same geopotential, which combines gravitational potential energy and centrifugal potential energy. Apart from temporary tidal fluctuations, gravity acts perpendicular to the geoid everywhere, meaning plumb lines point perpendicular and bubble levels are parallel to it. This equipotential nature means the geoid corresponds to the free surface of water at rest under only Earth's gravity and rotation, and it is also a sufficient condition for a ball to remain at rest rather than rolling. Earth's gravity acceleration is non-uniform over the geoid. The geoid is often expressed as a geoid undulation or geoidal height above a reference ellipsoid, a slightly flattened sphere whose equatorial bulge results from planetary rotation. Generally, the geoidal height rises where Earth's material is locally denser, exerting greater gravitational force. The geoid surface is irregular but considerably smoother than Earth's physical surface; while the ground has excursions of about +8,800 meters (Mount Everest) and -11,000 meters (Marianas Trench), the geoid's deviation from an ellipsoid ranges from +85 meters (Iceland) to -106 meters (southern India), totaling less than 200 meters. If the ocean were constant density and undisturbed, its surface would resemble the geoid; the permanent deviation between the geoid and mean sea level is called ocean surface topography. Geo
- field
- Geodesy, Geophysics
- known_for
- Mathematical figure of the Earth, reference for vertical coordinates, essential for GPS
- first_described_by
- Carl Friedrich Gauss
- first_high_fidelity_synthesis
- Gladys West (from satellite data)
Lore & Background
The geoid is the irregular, undulating surface that the ocean would form if only Earth’s gravity and rotation acted on it, with no winds, tides, or currents. It is smoother than Earth’s physical surface—whose extremes exceed 8,800 meters above and 11,000 meters below sea level—but its deviation from a reference ellipsoid (a flattened sphere) is less than 200 meters total, ranging from about +85 meters near Iceland to –106 meters in southern India. This surface extends through continents via hypothetical narrow canals, and its shape results from uneven mass distribution within Earth, such as dense magma, mountain ranges, and deep trenches. The geoid is an equipotential surface: gravity acts perpendicular to it everywhere (ignoring tides), so plumb lines are perpendicular and bubble levels are parallel to it. It can only be determined through extensive gravitational measurements and calculations, and was not precisely defined until satellite geodesy in the mid-20th century. Mathematician Gladys West was the first to synthesize a high-fidelity geoid from satellite data. The geoid serves as a reference for vertical coordinates like orthometric heights, and its undulation above a reference ellipsoid is used in GPS systems to correct satellite-based height readings.
Reader's Guide
It provides the reference surface for orthometric heights, geopotential heights, and dynamic heights, and is critical for converting GPS ellipsoidal heights to orthometric heights above mean sea level. The geoid's irregular shape reflects Earth's internal mass distribution, rising where material is denser and pulling more water. Its determination relies on combining terrestrial gravimetry, satellite orbital perturbations, and satellite gravity missions, as well as formulas like Stokes' integral. The geoid's role in global positioning systems makes it indispensable for modern navigation, mapping, and surveying.
Did You Know?
- Mathematician Gladys West was the first person to synthesize a high-fidelity geoid from satellite data.
- All points on a geoid surface have the same geopotential, and gravity acts perpendicular to it everywhere.
- GPS receivers on a ship may indicate height variations even at sea level because they measure heights relative to a geocentric reference ellipsoid, not the geoid.
Frequently Asked Questions
What is the geoid in simple terms?
The geoid is the surface the ocean would form if it settled purely under Earth's gravity and spin, with no wind or tides pushing it around. It is a single equipotential surface—gravity pulls perpendicular to it everywhere—but it is lumpy rather than a perfect sphere because Earth's internal mass is unevenly distributed.
Who first described the geoid?
Carl Friedrich Gauss introduced the concept, dubbing it the 'mathematical figure of the Earth' to capture the planet's true gravitational shape. His theoretical framing became the foundation that modern geodesy still builds upon.
Why is the geoid critical for GPS and elevation data?
Satellite positioning systems need the geoid as the zero-reference surface that converts raw satellite-to-receiver distances into orthometric heights (the 'above sea level' numbers you see on a map). Without an accurate geoid model, reported elevations could be wrong by tens of meters.
Who created the first high-fidelity geoid model from satellite data?
Gladys West is credited with turning the geoid from a purely theoretical construct into a high-resolution, satellite-derived surface. Her synthesis allowed geodesists to use the geoid as a practical, measurable reference for global height systems.
