Magnetite
Most magnetic naturally occurring mineral, key to paleomagnetism and compasses.
Magnetite is a mineral and a major source of iron, with the formula Fe2+Fe3+2O4. This iron oxide is ferrimagnetic, meaning it responds to a magnet and can itself be turned into a permanent magnet. Apart from very rare deposits of native iron, it is the most magnetic mineral found in nature. Naturally magnetized pieces, known as lodestone, can attract small bits of iron, and it was through lodestone that ancient peoples first encountered magnetism.
The mineral appears black or brownish-black with a metallic shine, has a Mohs hardness of 5 to 6, and leaves a black streak. Tiny grains of magnetite are widespread in igneous and metamorphic rocks. Its IUPAC name is iron(II,III) oxide, and it is commonly called ferrous-ferric oxide.
Beyond igneous rocks, magnetite also turns up in sedimentary settings such as banded iron formations, and in lake and marine sediments as both detrital grains and magnetofossils. Nanoparticles of magnetite are thought to form in soils, where they likely oxidize quickly into maghemite.
The chemical makeup of magnetite is Fe2+(Fe3+)2(O2-)4, showing it contains both ferrous (divalent) and ferric (trivalent) iron, which suggests it crystallizes in an environment with intermediate oxygen levels. Its structure was largely worked out in 1915, making it one of the first crystal structures solved using X-ray diffraction. It has an inverse spinel structure: O2- ions form a face-centered cubic lattice, with iron cations filling the gaps. Half of the Fe3+ ions sit in tetrahedral sites, while the other half, along with Fe2+ ions, occupy octahedral sites. The unit cell holds thirty-two O2- ions and has a length of 0.839 nm. As an inverse spinel, magnetite can form solid solutions with similar minerals like ulvospinel (Fe2TiO4) and magnesioferrite (MgFe2O4). Titanomagnetite, or titaniferous magnetite, is a solid solution between magnetite and ulvospinel that crystallizes in many mafic igneous rocks. During cooling, it may undergo oxy-exsolution, producing ingrowths of magnetite and ilmenite.
Natural and synthetic magnetite most often forms octahedral crystals bounded by {111} planes, as well as rhombic-dodecahedra. Twinning occurs on the {111} plane. Hydrothermal synthesis typically yields single octahedral crystals up to 10 millimeters across. With mineralizers like 0.1 M HI or 2 M NH4Cl at 0.207 MPa and 416–800 °C, magnetite grows as crystals combining rhombic-dodecahedral forms, which are more rounded than usual. The appearance of these higher forms is thought to result from a decrease in surface energy due to the lower surface-to-volume ratio in rounded crystals.
Magnetite has been key to understanding rock formation conditions. It reacts with oxygen to form hematite, and this mineral pair acts as a buffer controlling how oxidizing the environment is (oxygen fugacity), known as the hematite-magnetite (HM) buffer. At lower oxygen levels, magnetite forms a buffer with quartz and fayalite (the QFM buffer). At even lower oxygen levels, it forms a buffer with wüstite (the MW buffer). The QFM and MW buffers are widely used in laboratory experiments on rock chemistry; the QFM buffer, in particular, produces an oxygen fugacity close to that of most igneous rocks. Igneous rocks often contain solid solutions of titanomagnetite and hemoilmenite or titanohematite. The compositions of these mineral pairs are used to calculate oxygen fugacity, revealing a range of oxidizing conditions in magmas that influence how magmas evolve through fractional crystallization. Magnetite also forms from peridotites and dunites during serpentinization.
Lodestones served as an early form of magnetic compass. Magnetite is a critical tool in paleomagnetism, which is important for understanding plate tectonics and provides historical data for magnetohydrodynamics and other fields. The relationships between magnetite and other iron oxide minerals like ilmenite, hematite, and ulvospinel have been heavily studied; reactions between these minerals and oxygen affect how and when magnetite preserves a record of Earth's magnetic field. At low temperatures, magnetite undergoes a crystal structure phase transition from monoclinic to cubic, known as the Verwey transition. Optical studies show this metal-to-insulator transition is sharp and occurs around 120 K. The Verwey transition depends on grain size, domain state, pressure, and iron-oxygen stoichiometry. An isotropic point occurs near the Verwey transition around 130 K, where the sign of the magnetocrystalline anisotropy constant flips from positive to negative. The Curie temperature of magnetite is 580 °C (853 K; 1,076 °F). In large enough quantities, magnetite can be detected in aeromagnetic surveys using a magnetometer that measures magnetic intensities.
Solid magnetite particles melt at about 1,583–1,597 °C (2,881–2,907 °F).
Magnetite is sometimes found in large amounts in beach sand. Such black sands (mineral sands or iron sands) occur in places like Lung Kwu Tan in Hong Kong; California, United States; and the west coast of the North Island of New Zealand. The magnetite, eroded from rocks, is carried to the beach by rivers and concentrated by wave action and currents. Huge deposits have been found in banded iron formations, which are sedimentary rocks.
- chemical_formula
- Fe2+Fe3+2O4
- iupac_name
- iron(II,III) oxide
- common_name
- ferrous-ferric oxide
- mohs_hardness
- 5–6
- crystal_structure
- inverse spinel, face-centered cubic lattice
Lore & Background
It has an inverse spinel structure with O2- ions forming a face-centered cubic lattice and iron cations occupying interstitial sites. Magnetite can form solid solutions with ulvospinel and magnesioferrite, and titanomagnetite is a solid solution between magnetite and ulvospinel that crystallizes in many mafic igneous rocks. Magnetite reacts with oxygen to produce hematite, forming the hematite-magnetite buffer that controls oxygen fugacity. At lower oxygen levels, it forms buffers with quartz and fayalite (QFM) or with wüstite (MW), used extensively in laboratory experiments on rock chemistry. Magnetite also occurs in fossils as magnetofossils due to biomineralization, and in meteorites. Biomagnetism is usually related to biogenic crystals of magnetite, found in organisms from magnetotactic bacteria to humans, where they account for effects of weak magnetic fields on biological systems.
Reader's Guide
Magnetite's significance spans multiple scientific fields. As the most magnetic naturally occurring mineral, it was central to the discovery of magnetism through lodestones, which were used as early magnetic compasses. In paleomagnetism, magnetite is a critical tool for understanding plate tectonics and providing historic data for magnetohydrodynamics. Its magnetic properties, including the Verwey transition and Curie temperature, allow it to preserve a record of Earth's magnetic field. The mineral's reactions with oxygen and other iron oxides help determine oxidizing conditions in magmas and influence how magmas evolve by fractional crystallization. Magnetite's presence in banded iron formations has been used to infer changes in Earth's atmospheric oxygen content. Biologically, magnetite crystals in magnetotactic bacteria form magnetosomes used for navigation, and similar crystals in birds' upper beaks contribute to magnetoreception. The mineral's ability to affect compass navigation, as seen in Tasmania, underscores its practical importance. Its widespread occurrence in igneous, metamorphic, and sedimentary rocks, as well as in soils and marine sediments, makes it a key indicator in geological and environmental studies.
Did You Know?
- Magnetite crystals are biomineralized in magnetosomes by several species of magnetotactic bacteria.
The Lodestone Name
Lodestone is identified in the source material as a synonym of magnetite, catalogued among names that are not valid species. This means that while magnetite holds the recognized mineral species designation, lodestone functions as an alternative label pointing to the very same substance. Within the broader mineralogical framework described, species are set apart by their chemical composition and crystal structure, and variations in physical properties or minor impurities within a species may be acknowledged as distinct varieties. The lodestone designation, however, does not represent a separate variety or an independent species at all; it is simply another word for magnetite itself. This places it in a category distinct from true variety names, which denote recognizable differences within an established species. The list explicitly groups such synonyms alongside entries that have not received approval from the International Mineralogical Association, underscoring that the naming landscape surrounding magnetite involves layers of historical usage, formal recognition, and taxonomic precision that mineralogists must carefully navigate when cataloguing the mineral world.
Taxonomic Position Among Mineral Names
In the alphabetical listing of mineral names, magnetite occupies a position defined by its valid species status, while its synonym lodestone appears separately under the letter L among entries that are not valid species. The framework described in the source material draws a clear line: valid mineral species are defined by specific chemical compositions and crystal structures, whereas variety names represent recognized variations—differences in physical properties or the presence of minor impurities—within an already-established species. Magnetite, as a valid species, stands apart from the numerous variety names that populate the list, such as amethyst (a purple quartz) or aquamarine (a light blue beryl). The lodestone entry, labeled explicitly as a synonym rather than a variety, signals that it does not denote a compositional or structural variant of magnetite but rather a historical or colloquial alternative for the same mineral. This taxonomic clarity helps mineralogists and the wider public distinguish between genuinely distinct substances and merely different labels applied to the same one.
The IMA and Mineral Name Validation
The source material references the International Mineralogical Association as the authority for a complete listing of all mineral names, and several entries in the list carry the note that they are not approved by the IMA. This validation framework is central to understanding how magnetite and its synonym lodestone are situated in mineralogical discourse. A name that has not received IMA approval occupies a liminal space—it may appear in practice or in historical literature, but it lacks the formal standing of a recognized species or variety. Magnetite, by contrast, is treated as a valid species name, the kind that would appear in the IMA's complete catalogue. The distinction matters because it determines whether a name carries scientific weight in classification, research, and communication among mineralogists. The list's structure, which separates valid species from varieties and synonyms, reflects the IMA's role in maintaining order in a field where hundreds of names compete for recognition, and where a single mineral like magnetite can be known by multiple labels across different traditions and eras.
Distinguishing Features in a Crowded Taxonomy
The mineralogical framework described in the source emphasizes that species are set apart by differences in chemical composition and crystal structure, while varieties within a species are recognized through variations in physical properties or the inclusion of minor impurities. Magnetite, as a valid species, is defined by this first criterion—its specific chemistry and crystalline architecture make it distinct from neighboring minerals. The lodestone name, meanwhile, does not invoke any such distinguishing feature; it is catalogued purely as a synonym, a different word for the same entity. This contrasts sharply with the many variety names in the list, each of which points to a perceptible difference: the purple hue of amethyst, the green of chrysoprase, the fibrous habit of amosite. Magnetite's entry in the broader taxonomy, therefore, is defined less by a single striking physical trait and more by its formal chemical and structural identity, with lodestone serving as a reminder that even well-established species can carry alternative names that belong to no variety at all.
Frequently Asked Questions
What is Magnetite and what makes it stand out among minerals?
Magnetite is a naturally occurring iron oxide (Fe2+Fe3+2O4) that holds the title of the most magnetic mineral found on Earth, aside from the exceedingly rare native iron deposits. Its ferrimagnetic character means it is strongly attracted to magnets and can itself be magnetized into a permanent magnet.
What is lodestone and how does it connect to Magnetite?
Lodestone is simply a piece of Magnetite that has become naturally magnetized, and it was the material ancient peoples used to first stumble upon the phenomenon of magnetism. Without lodestone, the discovery of magnetic attraction would likely have been delayed by centuries.
What are Magnetite's physical properties like hardness and crystal structure?
On the Mohs scale Magnetite rates between 5 and 6, making it moderately hard and workable for polished specimens. It crystallizes in an inverse spinel structure with a face-centered cubic lattice, and its IUPAC name is iron(II,III) oxide.
Why is Magnetite important in science and history?
Magnetite is central to paleomagnetism because its locked-in magnetic signature records the orientation of Earth's field at the time the rock formed, letting researchers reconstruct continental drift. It also served as the raw material for the earliest compasses and remains a primary ore for iron smelting.
Is Magnetite the only magnetic mineral, or are there others?
A few other minerals show weak magnetic behavior, but Magnetite is by far the strongest natural magnet on Earth except for the extremely rare native iron deposits. Its ferrimagnetic ordering of iron ions within a spinel lattice gives it a net magnetic moment that other common iron oxides simply lack.
