The sound card mixer is the analog heart of a sound card, handling the routing and mixing of audio signals from both external connectors and the card's own digital-to-analog converters. It can select, mute, or amplify these signals with variable gain, then sum them and send the result to output connectors and the analog-to-digital converters. The mixing schemes used in most IBM-PC compatible computers are variants of the scheme defined in Intel's AC'97 Audio Component Specification.

Features of the mixer include audio channel remap, audio volume control, mixing multiple PCM audio streams, sample rate conversion, and audio bit depth conversion. Mixer controls are provided through the operating system's GUI, typically accessed via a Volume icon in the system tray. These controls resemble those of a mixing console, with volume sliders or rotary controls for each source, often accompanied by balance and mute controls. Most interfaces allow switching between playback (output) and recording (input) sources, and additional hardware or software may add effects such as low-pass filters, distortion, and boost controls.

For integrated sound cards (such as AC'97 or HD Audio based) or integrated sound chips (such as SoundWire based), a software-based mixer (such as KMixer, WASAPI, or Core Audio) is usually used. In a typical AC'97 style mixer scheme, the analog-to-digital converters that allow the CPU to receive audio signal can be connected directly to any input or to the same summation result provided via the line, aux, and mono analog outputs. In addition to input and output gain controls, the mixer provides controls for selecting the recording source, with the result subject to mute and gain control before digitization.
