Gravis UltraSound

Lore & Background

The GF1 chip was derived from the Ensoniq OTTO (ES5506) chip, a next-generation version of the synthesizer chip found in the Ensoniq VFX and its successors. The GF1 is purely a sample-based synthesis chip with no built-in codec; sounds must be downloaded to onboard RAM before playback. It does not support hardware compression like IMA ADPCM, so compressed samples must be decompressed prior to loading. The sound quality depends on the selected polyphony level, which is software-programmable, allowing programmers to balance quality and voice count. Advanced effects such as reverberation and chorus are not supported in hardware, though software simulation is possible.

The UltraSound offered MIDI playback by loading instrument patches into adapter RAM, similar to how instruments are stored in ROM on other wavetable cards. The card came with a 5.6 MB set of instrument patch files (*.PAT), most sampled at 16-bit resolution and looped to save space. Support programs used .INI files to describe patch loading for each program change event, allowing Gravis to incorporate a General MIDI-compatible mapping scheme. Windows 95 and 98 drivers used UltraSound.INI to load patches on demand; in DOS, patch loading could be configured separately.

Reader's Guide

The Gravis UltraSound's significance lies in its role as an early affordable wavetable synthesis card for the PC, offering 32-voice polyphony and user-upgradeable sample RAM at a time when most PC sound cards relied on FM synthesis. Its architecture, based on the GF1 chip derived from the Ensoniq OTTO, allowed musicians and game developers to use realistic instrument samples. However, its Sound Blaster emulation was criticized, and native game support was limited, leading Computer Gaming World in 1993 to recommend it primarily for Windows MIDI musicians. The GUS spawned multiple versions and clones, including the UltraSound MAX, Plug & Play, ACE, and OEM variants from companies like Synergy and Primax. The card's legacy continued into the 2010s and 2020s with hobbyist projects such as the PicoGUS (based on the RP2040 microcontroller) and the MK1869 Xtreme, which combined the AMD InterWave chip with an ESS ES1869. These efforts demonstrate the enduring interest in the GUS's unique sample-based synthesis capabilities and its place in retro-computing.

Did You Know?

• The GF1 chip was co-developed by Advanced Gravis and Forte Technologies, creator of the VFX1 Headgear virtual reality helmet.
• The UltraSound Classic was one of the first PC sound cards to feature 16-bit stereo audio.
• The UltraSound ACE was marketed as a competitor to Wave Blaster-compatible cards and was meant to be installed alongside a Sound Blaster Pro/16 card.
• The PicoGUS, an open-source design started in 2022, uses a Raspberry Pi RP2040 microcontroller to emulate the GUS and also supports Tandy 3 Voice, Game Blaster, and Sound Blaster 2.0.
