Lock (water navigation)
A waterway chamber that raises or lowers boats between different water levels.
A lock is a navigation structure that moves boats between waterway sections at different heights. Its key component is a fixed chamber where the water level can be raised or lowered. Unlike a caisson lock, boat lift, or canal inclined plane—where the chamber itself moves—a standard lock keeps the chamber stationary. Locks improve river navigation or let canals cross uneven terrain. Over time, canals have adopted larger and more numerous locks to create more direct routes.
**History**
In ancient Egypt, river locks probably existed along the Canal of the Pharaohs. According to Diodorus Siculus, engineers under Ptolemy II invented the lock around 274–273 BC to keep saltwater out of the Nile.
In ancient China, between 960 and 1279 CE, the flash lock evolved into a pound lock by adding an upper gate (or pair of gates), creating a short intermediate basin. The *Songshi* (History of the Song Dynasty) records that around 984, tax official Qiao Weiyue, frustrated by grain barge wrecks on the West River near Huai'an, discovered soldiers colluding with bandits to wreck imperial barges and steal grain. He built two sluice-gates 250 feet apart, roofed over like a building. By placing two staunch gates close together, he formed a short canal stretch—effectively a pound lock—filled from above by raising wooden baulks in the top gate and emptied into the lower canal by lowering baulks in the top gate and raising them in the lower.
In medieval Europe, a sort of pound lock was built at Vreeswijk, Netherlands, in 1385, serving many ships in a large basin. The first true European pound lock was built in 1396 at Damme near Bruges, Belgium. Between 1452 and 1458, Italian engineer Bertola da Novate constructed 18 pound locks on the Naviglio di Bereguardo, part of the Milan canal system sponsored by Francesco Sforza.
**Basic Operation**
Every pound lock has three parts: a watertight chamber fixed in place but with a variable water level, large enough for one or more boats; a gate (often a pair of pointing half-gates) at each end, watertight when closed; and lock gear to fill or empty the chamber, usually a simple valve (traditionally a flat paddle lifted by a hand-cranked rack and pinion) that lets water in or out. Larger locks may use pumps.
Operating a lock is straightforward. For a boat going downstream: if the chamber is low, it is filled via the upstream valve; the upstream gates open, the boat enters; the upstream gates close; the chamber drains through the downstream valve until the water matches the downstream level; the downstream gates open, and the boat exits. For an upstream boat, the process reverses. The whole operation takes 10 to 20 minutes, depending on lock size and whether the chamber was already at the boat’s level or the opposite level when the boat arrived. Boaters often welcome meeting another boat coming toward them, because that boat will have just left the lock at their level, setting the lock in their favor and saving 5 to 10 minutes. This does not apply to staircase locks, where convoy passage is quicker and uses less water.
**Historic Lock Designs**
These designs are no longer used for new locks, having been replaced by better ones.
Around 1800, Robert Weldon proposed a caisson lock for the Somerset Coal Canal in England. This underwater lift had a chamber 80 feet long and 60 feet deep, containing a completely enclosed wooden box big enough for a barge. The box moved up and down in the 60-foot-deep pool. Apart from leakage, water never left the chamber, so the lock wasted no water. The boat entered the box, the door sealed shut, and the box itself moved up or down through the water. At the bottom, the box was under nearly 60 feet of water—at a pressure of three atmospheres. One such lock was built and demonstrated to the Prince Regent (later George IV), but engineering problems prevented its use on the Coal Canal.
To save money, especially where good stone was too expensive or hard to get, composite locks were built using rubble or inferior stone, with the inner walls lined with wood to prevent abrasion to boats. This was done, for example, on the Chesapeake and Ohio Canal near the Paw Paw Tunnel and on the Chenango Canal.
In 1813, possibly inspired by Weldon’s caisson lock, William Congreve patented a “hydro-pneumatic double balance lock” featuring two adjacent...
- field
- Waterway engineering
- key_innovation
- Pound lock with two gates and a chamber
- typical_operation_time
- 10 to 20 minutes
Lore & Background
In ancient Egypt, river locks were probably part of the Canal of the Pharaohs. This type of lock, called a pound lock, was first used in medieval China during the Song dynasty. The Songshi records how Qiao Weiyue, a high-ranking tax administrator, was frustrated at frequent losses incurred when his grain barges were wrecked on the West River near Huai'an. He installed a pair of sluice-gates two hundred and fifty feet apart, the entire structure roofed over like a building, creating a short stretch of canal that functioned as a pound lock. In medieval Europe, a sort of pound lock was built at Vreeswijk, Netherlands in 1385, and the first true European pound lock was built in 1396 at Damme near Bruges, Belgium. The Italian Bertola da Novate constructed eighteen pound locks on the Naviglio di Bereguardo between 1452 and 1458. A lock is a device for raising and lowering watercraft between stretches of water at different levels on rivers and canals. Its distinguishing feature is a fixed chamber in which the water level can be varied. All pound locks have three elements: a watertight chamber connecting upper and lower canals, a gate at each end, and lock gear to empty or fill the chamber. The gates are often a pair of pointing half-gates that close against each other at an 18° angle to approximate an arch against water pressure. The lock gear is usually a simple valve, traditionally a flat panel lifted by manually winding a rack and pinion mechanism. Larger locks may use pumps. The operation takes between ten and twenty minutes. Historic lock designs include the caisson lock, proposed around 1800 for the Somerset Coal Canal in England, where a completely enclosed wooden box moved up and down in a deep pool of water, wasting no water.
Reader's Guide
This pound lock serviced many ships at once in a large basin. All pound locks have three elements: a watertight chamber, a gate at each end, and lock gear to empty or fill the chamber. The principle of operating a lock is simple: for a boat travelling downstream, the chamber is filled, the upstream gates open, the boat enters, the gates close, the chamber is drained, and the downstream gates open. The whole operation usually takes between 10 and 20 minutes. Historic lock designs include the caisson lock, composite material locks, hydro-pneumatic canal lift, inclined plane, shaft lock, and turf-sided lock. The shaft lock at Minden has a fall of 12.7 metres and has eight tanks linked in pairs to the lock chamber, saving water.
Did You Know?
- The shaft lock at Minden has a fall of 12.7 metres and uses eight tanks to save water.
Frequently Asked Questions
What is a lock in water navigation?
A lock is a fixed-position chamber on a river or canal that lets operators raise or lower boats and ships between two stretches of water at different elevations. It is the core mechanism that makes uneven terrain passable for watercraft.
How does a pound lock actually move a boat up or down?
The vessel enters a sealed chamber between two gates, and water is either let in or drained to change the level inside that chamber. Once the interior matches the target water level, the far gate opens and the craft proceeds.
How long does it typically take to pass through a single lock?
Under normal operating conditions, a boat spends roughly 10 to 20 minutes inside a lock chamber while the water level is adjusted and the gates are cycled.
What is the key design innovation behind the modern pound lock?
The pound lock introduced a dedicated enclosed chamber flanked by two separate gates, allowing the water level inside to be independently controlled without disturbing either upstream or downstream levels.
Why are locks essential to canal and river engineering?
Without locks, a canal could only follow perfectly flat ground and a river would be unnavigable wherever its elevation changes. Locks let waterway engineers thread routes over hills and through variable river profiles, keeping trade and transport flowing.
