Liquid-mirror space telescope

Lore & Background

The concept includes several designs. In the twirled pail design, a pair of objects—one the mirror assembly and the other a counterweight possibly containing a camera assembly—are spun up to induce centripetal acceleration on the surface of the mirror assembly. The half toroid design spins a hollow torus to maintain centripetal acceleration against the inside wall, with the camera assembly in the center; the torus width is arbitrarily large, and optional pieces include a large flat mirror in the center to allow randomly orienting the mirror without frequently changing the axis of spin. The balloon design uses a balloon with reflective liquid on the inside that is spun up and deforms into a parabolic shape, with a flat mirror on the inside reflecting light to the concave surface. The continuous-acceleration rocket design accelerates a spacecraft by an ion thruster or similar, producing constant linear acceleration; the spacecraft carries a rotating liquid mirror with its axis parallel to the direction of acceleration, and the spacecraft can be accelerated in any direction so the mirror can be aimed in any direction.

Other possibilities for inducing a parabolic shape include magnetic fields on a viscous and partially magnetic liquid; internal pressures or surface tension effects on a reflective liquid; or creating the telescope while the reflective surface is liquid but depending on cooling effects to solidify the surface and then using that as the telescope main mirror.

In April 2022, NASA reported they would conduct the Fluidic Telescope Experiment (FLUTE) on the ISS as part of Axiom Mission 1 astronaut Eytan Stibbe's research portfolio. The research would test liquid lenses by using water injected with polymers in microgravity, utilizing buoyancy to even gravitational forces and cause weightlessness, to be later hardened by UV light or temperature in orbit. A 2025 study by the Technion in Israel concluded that while maneuvering the telescope to point at different points in space will cause tiny ripples on the surface of the mirror, the effect would be very slow, and the inner 80% of the aperture will still be optically functional even after 10 years of regular operation.

Reader's Guide

The liquid-mirror space telescope concept is significant because it offers a path to very large optical space telescopes at much lower cost than conventional glass mirrors of comparable performance. The source article describes multiple design approaches—twirled pail, half toroid, balloon, and continuous-acceleration rocket—each using artificial gravity to maintain the parabolic shape of a rotating liquid mirror, rather than relying on Earth's gravity as Earth-based liquid-mirror telescopes do. The concept's legacy is supported by early experimental work: in April 2022, NASA's Fluidic Telescope Experiment (FLUTE) on the ISS, part of Axiom Mission 1 astronaut Eytan Stibbe's research, tested liquid lenses in microgravity using water injected with polymers, with plans to harden them by UV light or temperature. A 2025 study from the Technion in Israel further validated the concept's practicality, finding that even after 10 years of regular operation, the inner 80% of the aperture would remain optically functional despite tiny ripples caused by maneuvering. The article also notes other possible shaping methods—magnetic fields, internal pressures or surface tension, and solidification by cooling—broadening the concept's potential. Overall, the liquid-mirror space telescope is presented as a promising, cost-effective approach for future large-aperture space observatories.

Did You Know?

• The concept uses artificial gravity instead of Earth's gravity to maintain the parabolic shape of the rotating liquid mirror.
• One design, the continuous-acceleration rocket, uses an ion thruster to produce constant linear acceleration, allowing the mirror to be aimed in any direction.
• A 2025 study by the Technion in Israel found that after 10 years of regular operation, the inner 80% of the aperture would still be optically functional despite ripples from maneuvering.
