In digital signal modulation, information bits modulate a carrier wave to a set of allowed phase, frequency, and amplitude states called a constellation. Typically, all states appear with equal probability because bits are equally likely to be 0 or 1. However, optimal transmission through most practical channels, such as the AWGN channel, requires non-equal probability of transmission symbols. Constellation shaping addresses this by sending some signal combinations more often and others less frequently.

Probabilistic constellation shaping directly modifies the probability mass function by applying a distribution matcher between user data and the mapper to constellation symbols. This technique gained interest in September 2016 when Nokia Bell Labs demonstrated working 1 Tbit/s data transmission channels between German cities, followed by Alcatel-Lucent and Bell Labs claiming 65 Tbit/s transmission over 6,600 km single mode fiber in laboratory trials in October 2016. The industry's first commercial field trial was completed in 2018 by China Telecom and Huawei Technologies.

Geometric constellation shaping modifies the distribution of transmission power by optimizing the constellation states themselves. In an AWGN channel, this typically means gathering more constellation points around small amplitudes and fewer at high amplitudes. Other channels may require clipping high-amplitude points due to amplifier efficiency issues, as seen in satellite links where APSK is preferred over QAM. Geometric shaping requires no distribution matcher, simplifying digital signal processing, but does not typically allow Gray code labeling, leading to performance degradation. Probabilistic shaping is thus slightly more effective than geometric shaping.
