Slotted line

Lore & Background

Slotted lines are used for microwave measurements and consist of a movable probe inserted into a slot in a transmission line. They are used in conjunction with a microwave power source and usually, in keeping with their low-cost application, a low cost Schottky diode detector and VSWR meter rather than an expensive microwave power meter. Slotted lines can measure standing waves, wavelength, and, with some calculation or plotting on Smith charts, a number of other parameters including reflection coefficient and electrical impedance. A precision variable attenuator is often incorporated in the test setup to improve accuracy. This is used to make level measurements, while the detector and VSWR meter are retained only to mark a reference point for the attenuator to be set to, thus eliminating entirely the detector and meter measurement errors. The parameter most commonly measured by a slotted line is SWR. This serves as a measure of the accuracy of the impedance match to the item under test. This is especially important for transmitting antennas and their feed lines; high standing wave ratio on a radio or TV antenna can distort the signal, increase transmission line loss and potentially damage components in the transmission path, possibly even the transmitter. Slotted lines are no longer widely used, but can still be found in budget applications. Their main drawback is that they are labour-intensive to use and require calculation, tables, or plotting to make use of the results. They need to be made with mechanical precision and the probe and its detector need to be adjusted with care, but they can give very accurate results.

Reader's Guide

Slotted lines have now largely been superseded, but are still found where capital costs are an issue. Their remaining uses are mostly in the millimetre band, where modern test apparatus is either prohibitively expensive or not available at all, and with academic laboratories and hobbyists. They are also useful as a teaching aid as the user is more directly exposed to basic line phenomena than with more sophisticated instruments. The slotted line works by sampling the electric field inside the transmission line with the probe. For accuracy, it is important that the probe disturbs the field as little as possible. For this reason the probe diameter and slot width are kept small (usually around 1 mm) and the probe is inserted in no further than necessary. It is also necessary in waveguide slotted lines to place the slot at a position where the current in the waveguide walls is parallel to the slot. The current will then not be disturbed by the presence of the slot as long as it is not too wide. For the dominant mode this is on the centre-line of the broad face of the waveguide, but for some other modes it may need to be off-centre. This is not an issue for the co-axial line because this operates in the TEM (transverse electromagnetic) mode and hence the current is everywhere parallel to the slot. The slot may be tapered at its ends to avoid discontinuities causing reflections. The disturbance to the field inside the line caused by the insertion of the probe is minimised as far as possible. There are two parts to this disturbance. The first part is due to the power the probe has extracted from the line and manifests as a lumped equivalent circuit of a resistor. This is minimised by limiting the distance the probe is inserted into the line so that only enough power is extracted for the detector to operate effectively. The second part of the disturbance is due to energy stored in the field around the probe and manifests as a lumped equivalent of a capacitor. This capacitance can be cancelled out with an inductance of equal and opposite impedance. Lumped inductors are not practical at microwave frequencies; instead, an adjustable stub with an inductive equivalent circuit is used to 'tune out' the probe capacitance. The result is an equivalent circuit of a high impedance in shunt across the line which has little effect on the transmitted power in the line. The probe is more sensitive as a result of this tuning and the distance it is inserted can be further limited as a result.

Did You Know?

• Slotted lines can measure standing waves, wavelength, reflection coefficient, and electrical impedance.
• A precision variable attenuator is often used in the test setup to eliminate detector and meter measurement errors.
• In waveguide slotted lines, the slot is usually cut along the centre of the broad wall of the waveguide.
• The detector is often mounted a distance λ/4 from the probe tip to convert its short-circuit appearance to an open circuit.
