DJI Phantom
The DJI Phantom series defined the modern consumer drone market.
The DJI Phantom is a line of quadcopter drones made by the Chinese company DJI. The first model, released in 2013, was an affordable, easy-to-use entry-level drone that stood out from competitors at the time. It is widely regarded as the first commercially successful recreational drone and a highly influential design, capturing the consumer market from hobbyists and professionals alike and popularizing the modern aerial photography drone.
The original Phantom (later called the Phantom 1) launched on January 7, 2013. It used a 2.4 GHz control link and a 2200 mAh LiPo battery for about 15 minutes of flight. It had no built-in camera but could carry a GoPro HERO via an optional mount. Its GPS-enabled NAZA-M autopilot allowed it to hover and resist wind automatically. A later camera-equipped variant, the Phantom FC40, featured a fixed FC40 camera recording 720p video at 30 FPS. It switched to 5.8 GHz for control, freeing the 2.4 GHz band for FPV downlink, and used an iOS/Android app with Wi-Fi and GPS modules to stream near-real-time video to a mobile device. The camera angle had to be set manually before flight.
The Phantom 2 Vision, released in October 2013, was the first model with a built-in camera. It used a one-axis motorized gimbal for 60 degrees of vertical tilt, recording 1080p video at 30 or 60 FPS and 14-megapixel stills to a microSD card. It included Wi-Fi, GPS position holding, return-to-home, a Naza-M flight controller, and self-tightening propellers. The app controlled the camera and displayed flight data. Its 5200 mAh battery provided 25 minutes of flight. The Phantom 2 (December 2013) was a camera-less version, but an optional two-axis Zenmuse H3-2D gimbal could mount a GoPro HERO3. The Phantom 2 Vision+ (April 2014) upgraded to a self-stabilizing three-axis gimbal with 90 degrees of tilt, allowing straight-down shots. A late-2014 V3.0 version added more powerful motors, electronic speed controllers, Model 9450 propellers, and an improved compass.
The Phantom 3 series launched in April 2015 with the Professional and Advanced models. They introduced a visual positioning system for holding position without GPS, improving indoor and outdoor stability. A Lightbridge video transmission system replaced Wi-Fi, offering a stable connection up to 5 km (range varies by market).
Quick Facts
- Aircraft Type
- Unmanned aerial vehicle
- National Origin
- China
- Manufacturer
- DJI
- Construction Date
- 2013–c. 2023
- Introduction
- January 2013
Facts from the source article.
Lore & Background
The Phantom series began with the Phantom 1 on January 7, 2013, a quadcopter that used 2.4 GHz for control and a 2200 mAh LiPo battery for about 15 minutes of flight. It lacked a built-in camera but could be fitted with an optional mount for a GoPro HERO camera, and its GPS-enabled NAZA-M autopilot allowed hovering with automatic wind resistance. After the success of the Phantom 2 Vision, DJI released a camera-equipped version of the Phantom 1 as the Phantom FC40, which used 5.8 GHz for control and a 2.4 GHz Wi-Fi connection for near-real-time aerial video on a mobile device.
The Phantom 2 Vision, released in October 2013, was the first model with a built-in camera, mounted on a one-dimensional gimbal and capable of 1080p video and 14-megapixel stills. The Phantom 2 Vision+ replaced that gimbal with a self-stabilizing three-axis unit in April 2014. The Phantom 3 series, starting in April 2015, introduced a visual positioning system and a Lightbridge video transmission system, with models offering 4K or 2.7K video. The Phantom 4, released in March 2016, brought a new shell design, obstacle avoidance using four cameras and an ultrasonic sensor, and features like ActiveTrack and TapFly. Later variants included the Phantom 4 Pro with a 20-megapixel 1-inch sensor, the Phantom 4 Advanced, the Phantom 4 RTK for mapping, and the P4 Multispectral agricultural model.
Reader's Guide
The DJI Phantom series is significant as the first commercially successful recreational drone, fundamentally reshaping the consumer drone market. Its accessibility and user-friendly design captured the market from both hobbyists and professionals, introducing the modern aerial photography drone form factor to the general public. The series evolved rapidly, with each generation adding capabilities that became industry standards: GPS-assisted hovering, built-in cameras, gimbal stabilization, obstacle avoidance, and autonomous flight modes like ActiveTrack and TapFly. The Phantom 3 introduced a visual positioning system for indoor flight and a Lightbridge video transmission system for extended range, while the Phantom 4 added obstacle avoidance and a push-and-release propeller locking mechanism. The Phantom 4 Pro and Advanced upgraded camera sensors to 1-inch CMOS, and the Phantom 4 RTK brought real-time kinematic positioning for surveying. The P4 Multispectral integrated a six-sensor camera array for agricultural use. Production of the Phantom 4 Pro V2.0 was suspended in late 2018 or early 2019 due to a parts shortage, but restarted in January 2020 after the supply issue was resolved.
Did You Know?
- The Phantom 4 introduced an obstacle avoidance system using four cameras and an ultrasonic sensor.
- The Phantom 4 RTK, released in October 2018, added a real-time kinematic positioning module for aerial mapping and surveying.
Frequently Asked Questions
What is the DJI Phantom?
The DJI Phantom is a family of quadcopter drones produced by the Chinese manufacturer DJI, first introduced in 2013. It is best known as the drone that brought affordable, user-friendly aerial photography to the mainstream consumer market.
When did the original Phantom 1 launch and what set it apart?
The first model, originally simply called the Phantom, hit the market on January 7, 2013. At the time it stood out because it combined a low price point with a simple, beginner-friendly design that competitors had not yet matched.
What are the core specifications of the original Phantom 1?
The Phantom 1 used a 2.4 GHz radio control link, a 2200 mAh LiPo battery, and delivered roughly 15 minutes of flight time per charge. It was equipped with DJI's GPS-enabled NAZA-M autopilot for stable, hands-off hovering.
Why is the DJI Phantom considered a landmark in the drone hobby?
It is widely credited as the first commercially successful recreational drone, effectively defining what a modern consumer aerial-photography drone looks like. By appealing to both casual hobbyists and working professionals, it pulled the quadcopter out of the niche RC hobby and into the broader consumer market.
How did the Phantom change the RC model-aircraft landscape?
Before the Phantom, most RC flyers focused on helicopters, fixed-wing planes, and traditional multirotors that required significant skill to fly. The Phantom's integrated GPS autopilot and plug-and-play design lowered the barrier to entry so dramatically that it reshaped what the average model-aircraft enthusiast expected from a controllable flying machine.
