Hybrid drive
Hybrid drives combine SSD speed with HDD capacity.
A hybrid drive, also known as a solid-state hybrid drive (SSHD) or dual-storage drive, is a computer storage device that merges a faster storage medium, like a solid-state drive (SSD), with a larger-capacity hard disk drive (HDD). The goal is to bring some of the speed benefits of an SSD to the more affordable, high-capacity storage of a traditional HDD. In this setup, the SSD functions as a cache for data stored on the HDD, boosting overall performance by retaining copies of the most frequently accessed data on the quicker SSD.
There are two main ways to implement hybrid drives: dual-drive hybrid systems and solid-state hybrid drives. In dual-drive hybrid systems, separate SSD and HDD devices are installed in the same computer, with data placement optimization handled either manually by the user or automatically by the operating system, which creates a single hybrid logical device. In solid-state hybrid drives, both SSD and HDD functions are built into one piece of hardware. Here, data placement optimization is managed either entirely by the device itself (self-optimized mode) or through placement hints provided by the operating system (host-hinted mode).
**Types**
Two main hybrid storage technologies combine NAND flash memory or SSDs with HDD technology: dual-drive hybrid systems and solid-state hybrid drives.
**Dual-drive hybrid systems** use separate SSD and HDD devices in the same computer. Performance optimization is handled in three ways: by the user manually placing frequently accessed data on the faster drive; by the operating system, which merges the SSD and HDD into a single hybrid volume (examples include ZFS hybrid storage pools, bcache and dm-cache on Linux, Intel Hystor, Apple Fusion Drive, and other Logical Volume Management implementations on OS X); or by external chipsets, such as flash cache modules (FCMs). FCMs combine separate SSD (often an mSATA module) and HDD components, with optimization managed through host software, device drivers, or both. Intel Smart Response Technology (SRT), which uses certain Intel chipsets and storage drivers, is a common example. What sets this dual-drive system apart from an SSHD is that each drive can still be addressed independently by the operating system if needed.
- First hybrid drives introduced
- 2007
- Seagate momentus psd and samsung spinpoi
- 128 MB or 256 MB
- Seagate momentus xt (first sshd) capacit
- 500 GB HDD with 4 GB NAND
- Second-generation seagate sshd capacity
- 750 GB HDD with 8 GB NAND
- Third-generation seagate laptop sshd cap
- 500 GB and 1 TB, both with 8 GB NAND
- Toshiba first sshd capacity and nand
- Up to 1 TB with 8 GB SLC NAND
- Apple fusion drive released
- November 2012
Lore & Background
Hybrid-drive technology saw considerable advance over the decade beginning in 2007. In 2007, Seagate and Samsung introduced the first hybrid drives with the Seagate Momentus PSD and Samsung SpinPoint MH80 products. Both models were 2.5-inch drives, featuring 128 MB or 256 MB NAND flash memory options. Seagate's Momentus PSD emphasized power efficiency for a better mobile experience and relied on Windows Vista's ReadyDrive. The products were not widely adopted. In May 2010, Seagate introduced a new hybrid product called the Momentus XT and used the term solid-state hybrid drive. This product focused on delivering the combined benefits of hard drive capacity points with SSD-like performance. It shipped as a 500 GB HDD with 4 GB of integrated NAND flash memory. In November 2011, Seagate introduced what they referred to as their second-generation SSHD, which increased the capacity to 750 GB and pushed the integrated NAND flash memory to 8 GB. In March 2012, Seagate introduced their third-generation laptop SSHDs with two models: a 500 GB and 1 TB, both with 8 GB of integrated NAND flash memory. In September 2012, Toshiba announced its first SSHD, delivering SSD-like performance and responsiveness by combining 8 GB of Toshiba's own SLC NAND flash memory and innovative, self-learning algorithms with up to 1 TB of storage capacity. In September 2012, Western Digital (WD) announced a hybrid technology platform pairing cost-effective MLC NAND flash memory with magnetic disks to deliver high-performance, large-capacity integrated storage systems. In November 2012, Apple Inc. released the factory-configured dual-drive hybrid system named Fusion Drive. In October 2015, TarDisk introduced the plug-and-play dual-drive hybrid system 'TarDisk Pear', with flash memory size options up to 256 GB. In August 2021, Western Digital introduced OptiNAND, a New Flash-Enhanced HDD Architecture. It uses a new iNAND read/write cache system for performance. This feature is for when power is lost during a write phase, to prevent data loss. The System-on-a-Chip (SoC) of an OptiNAND drive, in under a second, will use the rotational power generated by the already spinning disk platter inside the drive to power internal capacitors until the iNAND cached data transfers to non-volatile NAND.
Reader's Guide
Hybrid drives represent a practical compromise between the speed of solid-state drives and the cost-effective capacity of hard disk drives. Their significance lies in offering improved performance for frequently accessed data—such as boot files and commonly used applications—without requiring the user to purchase a large, expensive SSD. The technology evolved through two main configurations: dual-drive hybrid systems, where separate SSD and HDD devices are managed manually or by the operating system (e.g., Apple's Fusion Drive, Intel Smart Response Technology), and solid-state hybrid drives (SSHDs), which integrate NAND flash memory directly into a single hard disk drive unit. SSHDs operate in self-optimized mode, where the device independently identifies hot data, or host-hinted mode, where the operating system provides placement hints via extended SATA commands. Benchmark testing from late 2011 and early 2012 found that SSHDs did not offer SSD performance on random read/write and sequential read/write, but were faster than HDDs for application startup and shutdown. A 2011 benchmark that loaded an image of a heavily used system found that in real-world tests, performance was much closer to an SSD than to a mechanical HDD. The legacy of hybrid drives includes their role in bridging the gap between HDD and SSD technologies, particularly in laptops and consumer systems, before the widespread price drops of pure SSDs.
Did You Know?
- The first hybrid drives, introduced in 2007, featured only 128 MB or 256 MB of NAND flash memory.
- Seagate's Momentus XT, released in May 2010, was the first product to use the term 'solid-state hybrid drive'.
- Apple's Fusion Drive, released in November 2012, is a dual-drive hybrid system, not an SSHD.
- Western Digital's OptiNAND, introduced in August 2021, uses rotational power from the spinning disk to prevent data loss during power failure.
