Short backfire antenna
A compact directional antenna with high gain and narrow bandwidth.
A short backfire antenna (also called SBA, SBF, or SBFA) is a directional antenna that offers high gain and a compact size, though it operates over a narrow frequency band. Its structure resembles a flat disc with a straight rim. A vertical pillar sits roughly in the center, carrying a dipole as the driven element, and a conductive disc on top serves as a sub-reflector. The bottom disc measures two wavelengths in diameter, and its rim is a quarter-wavelength tall. The central pillar is made of two coaxial tubes, with their diameters carefully chosen to achieve the desired impedance; a quarter-wavelength slot is cut into the outer tube. This assembly acts as a resonant cavity, producing significant gain within a small volume.
These antennas are used on some satellites and in high-frequency (short-wavelength) communication gear, often for ship-to-satellite links and other applications where rugged construction matters. They also appear in wireless LANs. Dr. Hermann W. Ehrenspeck of the Air Force Cambridge Research Labs (Hanscom Air Force Base, Bedford, MA) invented the short backfire antenna. It was employed, for example, to provide Tactical Satellite Communications for U.S. Army ground forces, thanks to its portability and gain. The antenna's bandwidth can be widened by using a conical main reflector instead of a flat one.
A later development, the archery target antenna, gets its name from its appearance. Its base diameter is five wavelengths, the rim height is 0.7 wavelengths, the small center reflector is 0.7 wavelengths in diameter and sits 0.7 wavelengths above the base, the dipole is 0.35 wavelengths above the base, and an annular reflector (inner diameter 2.2 wavelengths, outer diameter 3.7 wavelengths) is placed at the same height as the center reflector. Short backfire antennas can achieve high aperture efficiencies, and with the right cavity size, even exceed 100%.
- Inventor
- Dr. Hermann W. Ehrenspeck
- Inventor affiliation
- Air Force Cambridge Research Labs, Hanscom Air Force Base, Bedford, MA
- Bottom disc diameter
- 2 wavelengths
- Collar height
- quarter wavelength
- Center pillar
- two coaxial tubes with a quarter-wavelength slot cut into the outer tube
- Aperture efficiency
- can exceed 100% at right cavity size
Lore & Background
The short backfire antenna was invented by Dr. Hermann W. Ehrenspeck of Air Force Cambridge Research Labs based at Hanscom Air Force Base in Bedford, MA. It was used to provide Tactical Satellite Communications for U.S. Army ground forces due to its portability and gain. The antenna's structure consists of a bottom disc with a diameter of two wavelengths and a collar (edge) quarter a wavelength tall, a center pillar of two coaxial tubes with a carefully chosen diameter to give the desired impedance, and a quarter-wavelength slot cut into the outer tube. The top conductive disc acts as a sub-reflector, and the entire assembly functions as a resonant cavity.
Reader's Guide
Short backfire antennas are used in some satellites and in high-frequency (short-wavelength) communication equipment, often for communication with satellites, on ships and other applications where rugged construction is an advantage. They are also used for wireless LANs. The bandwidth of the antenna can be increased by using a conical main reflector instead of a flat one. The archery target antenna is an evolution of the short-backfire antenna, named for its appearance, with a base diameter of 5 wavelengths, a rim height of 0.7 wavelengths, and additional reflectors including a center reflector and an annular reflector. Short backfire antennas are able to achieve high aperture efficiencies, at right cavity size even beyond 100%.
Did You Know?
- Its bottom disc has a diameter of two wavelengths, and its collar is quarter a wavelength tall.
- The antenna can achieve aperture efficiencies beyond 100% at the right cavity size.
Breaking the Size Barrier: How Metamaterials Reshape Miniature Antennas
Conventional radio antennas face a hard physical constraint: to radiate efficiently, they must be at least half the wavelength of the signal they carry. At 300 MHz, that means a half-meter structure, making truly compact antennas inherently poor performers that bounce most of their energy back toward the transmitter. Metamaterial antennas sidestep this limitation by embedding engineered microscopic structures that store incoming electromagnetic energy and re-radiate it, effectively making the antenna behave as though it were far larger than its physical footprint. The newest experimental designs in this class launch up to 95 percent of the input radio signal into free space, while occupying as little as one-fiftieth of a wavelength. This dramatic shrinkage also widens the usable frequency band, allowing a single small element to cover more spectrum than its conventional counterpart. Because the negative refractive index of these materials focuses radiation through a flat lens rather than dispersing it, designers can pack high-gain radiating elements into dense arrays without sacrificing bandwidth, opening doors for satellite handsets, emergency communicators, micro-sensors, portable ground-penetrating radars, GPS receivers, and aircraft navigation systems.
The Double-Negative Shell: A Theoretical Leap in Antenna Efficiency
The foundational concept behind metamaterial antennas traces back to an analytical study of a tiny dipole wrapped in a shell of double-negative metamaterial, a substance sometimes called a negative-index or DNG medium. In that configuration, the surrounding shell acts as a natural impedance-matching network, taming the reactive component that normally chokes a sub-wavelength radiator. The result, confirmed both analytically and numerically, is roughly an order-of-magnitude boost in radiated power alongside a corresponding drop in reactance. A deeper mechanism at work is phase compensation: when a slab of conventional positive-index material is paired with a lossless DNG slab, and both are impedance-matched to the surrounding free space, a monochromatic plane wave propagating through the structure experiences a cancellation of accumulated phase delay. This principle of negative refraction also allows a flat metamaterial lens to concentrate electromagnetic energy rather than spread it, a capability that conventional optics cannot replicate without curved surfaces.
Ground Planes, MIMO Arrays, and Beam-Scanning Applications
Beyond shrinking individual radiators, metamaterials have proven transformative in the infrastructure surrounding antenna arrays. When metamaterial structures are integrated into the ground planes that sit beneath multiple-input multiple-output antenna arrays, they sharpen the electrical isolation between adjacent radio-frequency and microwave channels, reducing the cross-talk that plagues densely packed systems. High-impedance metamaterial ground planes simultaneously lift radiation efficiency and improve the axial-ratio performance of low-profile antennas mounted close to the surface, a critical advantage in compact satellite and aerospace hardware. In leaky-wave antenna architectures, engineers exploit both the forward and backward traveling waves supported by the metamaterial to extend the beam-scanning range well beyond what a conventional structure permits. These capabilities collectively underpin surveillance sensor networks, military communication links, navigation aids, and command-and-control installations. Manufacturing remains straightforward because established lithography processes can print the metamaterial elements directly onto standard printed-circuit boards, keeping production costs within reach of commercial and defense supply chains.
From Theoretical Wires to Commercial Products: A Two-Decade Arc
The materials science underpinning metamaterial antennas grew out of a sequence of landmark demonstrations. Pendry and colleagues first showed that a three-dimensional lattice of thin intersecting wires could yield a negative effective permittivity, while a periodic array of copper split-ring resonators could produce a negative effective permeability. In May 2000, Smith and a team of researchers made the first successful physical combination of those split-ring resonators with conducting wire posts, creating a left-handed material exhibiting simultaneously negative permittivity, permeability, and refractive index in the gigahertz and microwave bands. Two years later, a new class of negative-refractive-index metamaterial emerged, built on periodic reactive loading of a two-dimensional transmission line and experimentally verified shortly after. Although early split-ring resonator designs carried measurable inefficiencies, they remained the workhorse building block of metamaterial research through at least 2009, valued for their practical electromagnetic flexibility. By that same year, metamaterial antennas had crossed into commercial availability, and researchers were already exploring tunable variants incorporating liquid crystals to shift operating frequency across the optical-to-radio spectrum, alongside novel subsystems such as cavity resonators, waveguides, and scatterers.
Novel Configurations and the Path Toward Tunable, Multi-Band Systems
Metamaterial antenna research extends well past simple miniaturization. Designers are assembling subsystems that pair double-negative slabs with double-positive slabs, or combine epsilon-negative and mu-negative layers, to create cavity resonators, waveguides, scattering elements, and radiators with tailored electromagnetic responses. One particularly promising direction involves embedding dynamic materials such as liquid crystals into the metamaterial structure, which makes the antenna tunable across a span of frequency bands from the optical down to the radio-frequency range without any mechanical reconfiguration. This tunability, combined with the ability to print metamaterial elements using standard lithography on printed-circuit-board substrates, means that a single physical antenna can be reprogrammed to serve wireless communication, space-vehicle navigation, satellite links, or airborne radar functions. The negative refractive index property further enables flat-lens focusing of electromagnetic radiation, replacing bulky curved optics. As these configurations mature, they promise to compress the footprint of everything from portable satellite terminals to wide-angle beam-steering arrays while preserving the high gain and bandwidth that large conventional arrays deliver.
Frequently Asked Questions
Who is Short backfire antenna?
Dr. Hermann W. Ehrenspeck developed the short backfire antenna while working at the Air Force Cambridge Research Labs at Hanscom Air Force Base in Bedford, Massachusetts. It is a compact directional antenna that packs high gain into a small footprint, though it trades that for a narrow operating band.
What are Short backfire antenna's powers/role?
The SBA delivers strong directional gain in a remarkably small package, making it a go-to choice whenever space is tight but performance still matters. Its main limitation is bandwidth—it only performs well over a narrow slice of the spectrum.
What does Short backfire antenna look like?
Picture a flat disc with a straight vertical rim, a central pillar carrying a dipole driven element, and a smaller conductive disc perched on top acting as a sub-reflector. The bottom disc spans two wavelengths in diameter, and the rim stands a quarter-wavelength tall.
Why is Short backfire antenna important?
When the cavity dimensions are dialed in correctly, the SBA can push its aperture efficiency above 100 percent, a feat that makes it a fascinating study in electromagnetic design. That unusual efficiency, combined with its compact form, keeps it a recurring talking point in antenna theory circles.
