Grid fin

Grid fins, also called lattice fins, are flight control surfaces used on rockets and bombs as an alternative to conventional planar fins. Their defining feature is a lattice of small aerodynamic surfaces set within a frame, giving them a boxy appearance often compared to potato mashers or waffle irons. This design allows them to fold flat against a missile’s body more compactly than planar fins, which is useful for tube-launched weapons or internal bays on stealth aircraft; they typically pivot outward after launch.

Because grid fins have a much shorter chord—the distance from leading to trailing edge—than planar fins, high-speed airflow exerts less torque on the steering mechanism. This permits smaller fin actuators and a smaller tail assembly overall. They perform well at subsonic and supersonic speeds but poorly at transonic speeds, where a normal shockwave forms within the lattice, causing much of the airflow to bypass the fin and generating significant wave drag. At high Mach numbers, the flow becomes fully supersonic, and grid fins can offer lower drag and greater maneuverability than planar fins.

The concept was developed in the 1950s by a team led by Sergey Belotserkovskiy and saw use from the 1970s on Soviet ballistic missiles such as the SS-12 Scaleboard, SS-20 Saber, SS-21 Scarab, SS-23 Spider, and SS-25 Sickle, as well as the N-1 rocket intended for the Soviet moon program. In Russia, they are often called Belotserkovskiy grid fins. They have also been applied to conventional missiles and bombs, including the Vympel R-77 air-to-air missile, the 3M-54 Klub (SS-N-27 Sizzler) cruise missile family, and the American Massive Ordnance Air Blast (MOAB) bomb, plus specialized devices like the Quick-MEDS delivery system and the Soyuz spacecraft’s launch escape system.

SpaceX tested grid fins on a Falcon 9 first-stage demonstration vehicle in 2014, and on December 21, 2015, they guided a commercial Falcon 9 first stage during high-velocity atmospheric reentry, enabling the first successful orbital booster landing in history. The Chinese company i-Space’s Hyperbola-1 rocket first stage appeared on July 25, 2019 to have steerable grid fins for attitude control. That same day, China launched a modified Long March 2C with grid fins atop its first stage for controlled reentry away from populated areas.

Developed in
1950s
Lead developer
Sergey Belotserkovskiy
First used on ballistic missiles
1970s
First used on falcon 9 reusable first st
2015
First successful orbital booster landing
December 21, 2015
First hypersonic flight test with grid f
February 2015
Falcon 9 block 5 titanium grid fins firs
June 2017

Lore & Background

Grid fins were developed in the 1950s by a team led by Sergey Belotserkovskiy and have been used since the 1970s in various Soviet ballistic missile designs such as the SS-12 Scaleboard, SS-20 Saber, SS-21 Scarab, SS-23 Spider, and SS-25 Sickle, as well as the N-1 rocket intended for the Soviet moon program. In Russia, they are often referred to as Belotserkovskiy grid fins. They have also been used on conventional missiles and bombs including the Vympel R-77 air-to-air missile, the 3M-54 Klub cruise missile family, the American Massive Ordnance Air Blast (MOAB) bomb, the Quick-MEDS delivery system, and the launch escape system for the Soyuz spacecraft.

Design characteristics: Conventional planar control fins are shaped like miniature wings, whereas grid fins are a lattice of smaller aerodynamic surfaces arranged within a box, sometimes compared to potato mashers or waffle irons. Grid fins can be folded against the missile body for compact storage, important for tube-launched weapons or internal bays of stealth aircraft. They have a much shorter chord than planar fins, reducing torque on the steering mechanism and allowing smaller actuators. Grid fins perform well at subsonic and supersonic speeds but poorly at transonic speeds due to normal shockwave formation within the lattice; at high Mach numbers they provide lower drag and greater maneuverability than planar fins.

In 2014, SpaceX tested grid fins on a first-stage demonstration vehicle of its reusable Falcon 9 rocket, and on December 21, 2015 they were used during the high-velocity atmospheric portion of reentry to guide a commercial Falcon 9 first stage back to land for the first successful orbital booster landing. The first hypersonic flight test with grid fins was in February 2015. The Chinese company i-Space's Hyperbola-1 rocket appeared on July 25, 2019 to be equipped with steerable grid fins, and on the same date China launched a modified Long March 2C with grid fins atop the first stage for controlled re-entry.

Reader's Guide

Grid fins have become significant in the development of reusable launch vehicles, particularly for the SpaceX Falcon 9 rocket, where they provide increased precision and accuracy in controlling the landing location. The grid fin development effort is part of the SpaceX reusable launch system development program underway since 2012. After the first hypersonic flight test in February 2015, grid fins were used on all reusable Falcon 9 experimental test landings and, after December 2015, an increasing number of successful first stage landings and recoveries. Iteration on the design continued into 2017, with SpaceX CEO Elon Musk announcing a new version to improve reusability. The Falcon 9 Block 5 introduced new cast and cut titanium grid fins, replacing earlier aluminum fins that were coated with an ablative thermal protection system and had sometimes caught fire during entry and landing. The titanium fins enabled greater controllability and increased payload to orbit capability by allowing a higher angle of attack. These larger, unpainted titanium grid fins were first tested in June 2017 and have been used on all reusable Block 5 Falcon 9 first stages since late 2017. The legacy of grid fins thus extends from Cold War ballistic missiles to modern commercial reusable rocketry, demonstrating their adaptability across speed regimes and vehicle types.
