Flight envelope

Lore & Background

The term flight envelope is somewhat loosely applied and can also refer to other measurements such as maneuverability. When a plane is pushed, for instance by diving it at high speeds, it is said to be flown 'outside the envelope', something considered rather dangerous. During vehicle test programs, flight envelope simply means that part of the aircraft or spacecraft's design capabilities that have already been successfully tested, and have therefore moved from theoretical or designed capability into a demonstrated/certified capability.

The term has been widened in scope outside the field of engineering, to refer to the strict limits in which an event will take place or more generally to the predictable behavior of a given phenomenon or situation, and hence, its 'flight envelope'. It is closely related to more modern terms known as extra power and a doghouse plot, which are different ways of describing the flight envelope of an aircraft.

Extra power, or specific excess power, is a very basic method of determining an aircraft's flight envelope. It is easily calculated but as a downside does not tell very much about the actual performance of the aircraft at different altitudes. A doghouse plot generally shows the relation between speed at level flight and altitude, and takes more effort to make than an extra power calculation, but in turn provides much more information such as ideal flight altitude.

Reader's Guide

The flight envelope is significant because it defines the capabilities of an aircraft design in terms of airspeed and load factor or atmospheric density, often simplified to altitude. Although it is easy to compare aircraft on simple numbers such as maximum speed or service ceiling, an examination of the flight envelope reveals far more information. Generally a design with a larger area under the curve will have better all-around performance, because when the plane is not flying at the edges of the envelope, its extra power will be greater, meaning more power for climbing or maneuvering. General aviation aircraft have very small flight envelopes, with speeds ranging from perhaps 50 to 200 mph, whereas the extra power available to modern fighter aircraft result in huge flight envelopes with many times the area. As a trade-off, military aircraft often have a higher stalling speed, and as a result, the landing speed is also higher. The phrase 'pushing the envelope' is used to refer to an aircraft being taken to or beyond its designated altitude and speed limits, and by extension, this phrase may be used to mean testing other limits, either within aerospace or in other fields.

Did You Know?

• The flight envelope is the oldest common term for aircraft capability limits, first used in the early days of test flight.
• Flying 'outside the envelope' by diving at high speeds is considered rather dangerous.
• A doghouse plot resembles an upside-down U and is named for its resemblance to a kennel.
• The phrase 'pushing the envelope' has been extended outside aerospace to mean testing limits in other fields.
